Trendnet - TK-220DPi - 2-Port 4K DisplayPort KVM Switch
Part number:
TK-220DPi
Price:

TRENDnet’s 2-Port 4K DisplayPort KVM Switch, model TK-220DPi, allows you to control two computers with one set of console controls. Easily experience up to 4K UHD resolutions, no driver installation required. This compact DisplayPort switch is designed for 4K DisplayPort systems with USB mouse and keyboard connections. This UHD DisplayPort KVM switch also features 3.5mm speaker and microphone connections to switch between computers.



Features:

  • Control two computers with one set of console controls
  • Compatible with DisplayPort port monitors and TVs
  • Supports 4K UHD resolutions up to 3840 x 2160 @ 60Hz
  • 5.1 audio support over DisplayPort cables
  • 3.5mm speaker and microphone connections for analog audio
  • Fully integrated DisplayPort, USB, and audio cables
  • USB powered – No external power adapter required
  • Convenient computer toggle switch
  • NDAA / TAA compliant (U.S. and Canada only)
Console Port Connectors
  • Keyboard: USB Type A
  • Mouse: USB Type A
  • Monitors: 1 x DisplayPort 1.2
  • Speaker jack: 3.5mm
  • Microphone jack: 3.5mm
Computer Interface (up to 2)
  • Keyboard/Mouse: USB 2.0 Type A
  • Monitors: DisplayPort 1.2
  • Speaker jack: 3.5mm
  • Microphone jack: 3.5mm
  • Cable length: 1.5m (4.92 ft.)
Monitor Resolution
  • Up to 1920 x 1080 @ 144Hz
  • Up to 1920 x 1200 @ 144Hz
  • Up to 1920 x 1440 @ 144Hz
  • Up to 2560 x 1440 @ 144Hz
  • Up to 3440 x 1440 @ 60Hz
  • Up to 3840 x 2160 @ 60Hz
Switching Control
  • One touch toggle switch
  • Keyboard hot key commands
Audio Support
  • 5.1 Audio support over DisplayPort cables
  • Analog audio over speaker and microphone jacks
Operating Temperature
  • 0° – 40° C (32° – 104° F)
Operating Humidity
  • Max. 90% non-condensing
Dimensions
  • 164 x 87 x 45mm (6.4 x 3.4 x 1.77 in.)
Weight
  • 578g (1.27 lbs.)
Certifications
  • CE
  • FCC
Warranty
  • 2 year

PACKAGE CONTENTS

  • TK-220DPi
  • Quick Installation Guide
Name
Description
Size
Downloads
File
Datasheet
1.5mb
