Trendnet - TK-209K - 2-port USB KVM Switch Kit w/Audio (include 2 x KVM Cables)
Part number:
TK-209K
Price:

TRENDnet's 2-Port USB KVM Switch Kit with Audio, model TK-209K, allows you to control multimedia PCs with just one keyboard, monitor, mouse, microphone, and a set of speakers. The KVM switch not only allows you to share your monitor, keyboard and mouse, but you can also share microphone and speakers. With just a simple press of a button, this KVM switch eliminates the hassle of cable swapping and switching between 2 PCs. With its Hot-Plug, Auto-Scan, and Hot-Key operating features, the TK-209K KVM Switch is an ideal choice for managing 2 PCs.



Features:

  • 2-Port KVM switch with VGA, USB mouse and keyboard connections
  • Device monitoring with Auto-Scan and audible feedback
  • High quality 2048 x 1536 resolution for a crisp display
  • Supports most operating systems and advanced mouse designs
  • Control two computers with one set of console controls
  • Listen to music from one computer while working on another
  • Bus powered – No external power adapter required
  • All required cabling included
  • No CD installation required
  • NDAA compliant
Console Port Connectors
  • 1 x VGA /SVGA HDB 15-pin (Female)
  • 2 x USB ports (Keyboard / Mouse)
  • 2 x 3.5mm microphone/speaker jacks
Computer Interface (up to 2)
  • 1 x USB Type A
  • 1 x VGA /SVGA HDB 15-pin (Female)
  • 2 x 3.5mm audio jacks
Cables (2 sets)
  • Length: 1.2m (4 ft.)
  • VGA /SVGA (Male) to VGA /SVGA (Male) / USB Type A
  • 3.5mm Audio cables
Monitor Resolution
  • 2048 x 1536 @ 60Hz
Switching Control
  • Front panel push buttons
  • Keyboard hot key commands
Operating Temperature
  • 0° – 40° C (32° – 104° F)
Operating Humidity
  • Max. 90% non-condensing
Power
  • USB powered
  • Max. consumption: 0.7W
Dimensions
  • 95 x 63 x 24mm (3.74 x 2.48 x 0.95 in.)
Weight
  • 104g (3.6 oz.)
Certifications
  • CE
  • FCC
Warranty
  • 2 year

PACKAGE CONTENTS

  • TK-209K
  • Quick Installation Guide
  • 2 x KVM Cables (1.2m/4 ft.)
  • 2 x Audio Cables (1.2m/4 ft.)
Name
Description
Size
Downloads
File
Datasheet
0.1mb
