TRENDNET - TEG-S24g - 24-port Gigabit GREENnet Switch(Rack Mount)
Part number:
TEG-S24g
Price:

The 24-Port Gigabit GREENnet Switch, model TEG-S24g, provides high bandwidth performance, ease of use, and reliability, all while reducing power consumption by up to 70%*. GREENnet technology automatically adjusts power consumption as needed, resulting in substantial energy savings. Embedded GREENnet technology works right out of the box with no management requirement.



Boost office network efficiency and eliminate network congestion with gigabit speeds and a total switching capacity of 48Gbps with full-duplex mode. A built-in universal power supply reduces cable clutter, and diagnostic LEDs help with network troubleshooting. Plug and Play this sturdy metal switch for reliable high-speed network connectivity.



Features:

  • GREENnet technology reduces power consumption by up to 70%
  • 24 x Gigabit RJ-45 ports
  • Sturdy rackmount metal switch with built-in power supply
  • 48Gbps forwarding capacity
  • NDAA / TAA compliant (U.S. and Canada only)
  • Lifetime Warranty
Standards
  • IEEE 802.3
  • IEEE 802.3u
  • IEEE 802.3x
  • IEEE 802.3ab
  • IEEE 802.3az
Device Interface
  • 24 x Gigabit Ports
  • LED indicators
Data Transfer Rate
  • Ethernet: 10Mbps (half duplex), 20Mbps (full duplex)
  • Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex)
  • Gigabit: 2000Mbps (full duplex)
Performance
  • Data RAM Buffer: 0.5MB
  • Switch Fabric: 48Gbps
  • MAC Address Table: 8K entries
  • Forwarding rate: 35.7Mpps (64-byte packet size)
  • Jumbo Frame: 10KB
Special Features
  • GREENnet energy saving technology
  • Fanless
  • Rack mountable
Power
  • Internal power supply: 100-240V AC, 50/60Hz, 0.6A
  • Max. consumption: 13W
Operating Temperature
  • 0 – 40° C (32 - 104° F)
Operating Humidity
  • Max. 90 % non-condensing
Dimensions
  • 440 x 210 x 44mm (17 x 8.3 x 1.8 in.)
Weight
  • 2.3 kg (5 lbs.)
Certifications
  • CE
  • FCC
  • CB
  • UL / CUL
Warranty
  • Lifetime Warranty*

PACKAGE CONTENTS

  • TEG-S24g
  • Quick Installation Guide
  • Power cord
  • Rack mount kit
Name
Description
Size
Downloads
File
Datasheet
0.5mb
