Avycon - AVN-S24-2P24G - 24 Ports Gigabit Network with 2G SFP Uplink Ports
Part number:
AVN-S24-2P24G
Price:
This product is a type Gigabit Ethernet Switch. The machine comes with 16x10/100/1000Mbps RJ45 ports and 2 Gigabit SFP ports which can satisfy the full speed forwarding of ports. The machine uses 19 "1U"The standard chassis can be used on the desktop or on the rack. Excellent performance can help you widely use in wireless, monitoring and other fields.
Features:
- IEEE802.3, IEEE 802.3u, IEEE 802.3ab, IEEE802.3z
- Provides 16 10/100/1000 Base-TX ports, 2 1000M SFP ports
- Build in AC power
- High back-plane bandwidth 36Gbps
- 19” rack-mounted metal case
- Up to 8k MAC address table size
- Surge protection for power port and data ports
- Plug and Play design - no configuration required
- IEEE802.3x Flow control
- EMI standards complies with FCC, CE class B
| GENERAL | |
| Fixed Port | 24 x 10 / 100 / 1000 Base-TX Ports, 2 x 1000M SFP Ports |
| LED Indicators | PWR. 1000M, Link / Act LED |
| Input Voltage | 100V ~ 240V AC - 50/60 Hz |
| Network Standard | IEEE 802.3 10 Base-T IEEE 802.3u 108 Base-TX IEEE 802.3x Flow Control IEEE 802.3az |
| Network Media | 10BASE-TX: UTP category 5, 5e cable (≤250m) 100BASE-TX: UTP category 5, 5e cable (≤150m) 1000BASE-TX: UTP category 5, 5e cable (≤150m) Uplink Fiber Port: Single Fiber 20km, Double Fiber: 20km |
| Power Supply | 250W, 400W (500W optional) |
| Operating Temperature | 0°C ~ 40°C (32°F ~ 104°F) |
| Storage Temperature | -10°C ~ 70°C (14°F ~ 158°F) |
| Relative Humidity | 20% ~ 85% (Non-Condensing) |
| Thermal Management | Built-in Noiseless Fan |
| PoE Port | 16 /24 - 10 / 100 / 1000 Base-TX ports |
| PoE Standard | IEEE802.3af, IEEE802.3at, per port 15.4W, Max. 30W |
| Pin Assignment | V+ (RJ45 Pin 1, 2), V- (RJ45 Pin 3, 6) |
| Switching Capacity | 52G |
| MAC Address | 8K |
| Unit Size | 440mm x 200mm x 44mm |
| Weight | <5KG |
| Contents | AVN-S24-2P24G - POE Switch User Manual Warranty Card Power Cord*1 |
