WI-PS302G-UPS is a versatile 2-port PoE Switch with the functions of DC12V PoE switch and UPS PoE switch, featuring internal voltage booster, UPS battery control, switchable DC24V/48V and switchable PoE 48V and 24V.

As a DC 12V PoE Switch:

• Support DC 12V input from power adapter, vehicle battery or solar power
• One Ethernet data port 10/100/1000Mbps for LAN connection
• Provide one IEEE802.3af/at Standard 48V PoE output, or
• switchable to PoE 24V, max power output is 25W
• Provide one 12V 3A DC output (For NVRs, router, light, etc.)
• Provide one 24V/48V DC output (Optional)

As a UPS PoE Switch:

• Support 90 - 240V AC input
• Compatible with lead-acid and lithium battery as back up power
• One ethernet data port 10/100/1000Mbps for LAN connection
• Provide one IEEE802.3af/at Standard 48V PoE output, or
• switchable to PoE 24V, max power output is 25W
• Provide one 12V 3A DC output (For NVRs, router, light, etc.)
• Provide one 24V/48V DC output (Optional)

Features:

•  2 10/100/1000Mbps Ports UPS No-break PoE Injector
• Inside battery controller for charge and dis-charge
• 24-48V PoE output optional
• Support AC 90-240V in, 12V battery 30AH max
• Support DIN-rail Mount and wall-mount
• Small size design for outdoor CCTV system waterproof box
