Hanwha - SLA-H-4680VA - Height strip with 4.6mm pinhole lens module, compatible with PNM-9000QB, right angle body style, 2MP @ 30fps, 0.06 Lux, 73º horizontal field of view, 8 meters/ 26 feet cable
Part number:
SLA-H-4680VA
Price:
Height strip with 4.6mm pinhole lens module, compatible with PNM-9000QB, right angle body style, 2MP @ 30fps, 0.06 Lux, 73º horizontal field of view, 8 meters/ 26 feet cable
Features:
- Designed for easy installation
- Fits most standard door frames
- Durable aluminum construction
- Highly visible color-coded height levels
- Capture a person's face and approximate height
- 3 lens mounting positions
- Curved surface w/180? HFOV camera adjustment
- Wrap-around labels visible from side
- Includes lens, & housing. Compatible with PNM-9000QB, required (not included)
| VIDEO | |
| Imaging Device | 1/2.8" 2M CMOS |
| Total Pixels | 1,945(H) x 1,109(V) 2.16M |
| Effective Pixels | 1,945(H) x 1,097(V) 2.13M |
| Scanning System | Progressive Scan |
| MinimumIllumination | Color : 0.06Lux (F2.5) B/W : 0.06Lux (F2.5) |
| LENS | |
| Focal length | 4.6mm Fixed focal |
| Maximum Aperture ratio | F2.5 |
| Angular Field of View | H : 73° / V : 39° / D : 85° |
| Minimum Object Distance | 0.3m (0.98ft) |
| Mount Type | Shielded RJ-12 connected with main unit |
| OPERATIONAL | |
| Day & Night | Auto (Electrical) / Color / B/W |
| Backlight Compensation | Off / BLC / HLC / WDR |
| Wide Dynamic Range | 120dB |
| Contrast Enhancement | SSDR (Off / On) |
| Digital Noise Reduction | SSNRV (2D + 3D Noise filter) (Off / On) |
| Digital Image Stabilization | Off / On |
| Defog | Off / Auto / Manual |
| Gain Control | Off / Low / Middle / High |
| White Balance | ATW / AWC / Manual / Indoor / Outdoor (included Mercury & Sodium) |
| Contrast | Level adjustment |
| LDC (Lens Distortion Correction) | Off / On (5 Levels with min / max) |
| Electronic Shutter Speed | Minimum / Maximum / Anti flicker (2 ~ 1/12,000sec) |
| Digital PTZ | 24x, Digital PTZ (Preset, Group) |
| Flip / Mirror | Off / On |
| ENVIRONMENTAL | |
| Operating Temperature / Humidity | -10°C ~ +55°C (+14°F ~ +131°F) / Less than 90% RH |
| Storage Temperature / Humidity | -30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH |
| MECHANICAL | |
| Color / Material | White, with colored height strips Powder Coated Aluminum Cover, Powder Coated Steel Back Frame, Plastic Top Cap |
| Dimensions (WxHxD) | 866.1 x 43.7 x 35.1mm (1.72" x 34.10" x 1.38") |
| Weight | 2lbs (0.9kg) |
