Vivotek - AW-GEL-105A-110 - 2xGE bt 90W PoE+6xGE 30W PoE+1xGE UTP+1xGE SFP LiteManSwitch
Part number:
AW-GEL-105A-110
Price:
2xGE bt 90W PoE+6xGE 30W PoE+1xGE UTP+1xGE SFP LiteManSwitch
Features:
- Gigabit Ethernet
- 802.3 at/bt Hybrid
- Extend PoE 250M
| Model | AW-GEL-105A-110 |
| Product Description | 2xGE bt 90W PoE + 6xGE 30W PoE + 1xGE UTP + 1xGE SFP Lite Managed Switch |
Port Configuration
10M/100M/1G PoE port | - | 8 |
10M/100M/1G RJ45 Port | - | 1 |
100M/1G SFP Port | - | 1 |
| IEEE Standard | IEEE 802.3x IEEE 802.3u IEEE 802.3ab | V |
| Total Ports | - | 10 |
| HW Performance | - | |
| Switching Bandwidth | 20 Gbps | |
| Buffer Memory | 1.5 Mb | |
| MAC Address | 8K | |
| Jumbo Frames | 9216 Bytes | |
| Lite Managed Features | - | |
| VLAN | 802.1Q Tag-based VLAN | 4096 VLAN IDs |
| Port-based VLAN | V | |
| Spanning Tree Protocol | IEEE 802.1d (STP) | V |
| IEEE 802.1w (RSTP) | V | |
| Link Aggregation Control Protocol | - | V |
| QoS | CoS port-based | V |
| CoS 802.1p-based | V | |
| CoS DSCP-based | V | |
| Loop Protection | - | V |
| Flow Control | - | V |
| Storm Control | - | V |
| Port-Based Mirroring | - | V |
| Port Isolation | - | V |
| Bandwidth Control | - | V |
| Satic MAC | - | V |
| PoE Management | V | |
| PoE On/Off Control | V | |
| PoE Auto Checking | ||
| Non-Stop PoE | ||
| Model | AW-GEL-105A-110 |
| Product Description | 2xGE bt 90W PoE + 6xGE 30W PoE + 1xGE UTP + 1xGE SFP Lite Managed Switch |
| Extend PoE Mode (250M) | V |
| PoE Function | |
IEEE 802.3 PoE Standard Compliant | 802.3 af/at/bt |
| Number of PoE Output Port | 16 |
| PoE Output Power | Port 1-4 bt 90W Port 5-16 at 30W |
| Totoal PoE Power Budget | 260W |
PoE Pin Assignment | Port 1-4: 4 pairs 1/2 (-), 3/6 (+) and 4/5 (+), 7/8 (-) Port 5-16: 2 pairs 1/2 (-), 3/6 (+) |
| PoE Surge protection | 4KV Per PoE port |
| Environmental Specifications | |
| Operating Temperature | 0°C ~ 50°C (32°F ~ 122°F) |
Storage Temperature | -20°C ~ 70°C (-4°F ~ 158°F) |
| Operating Humidity | 10 ~ 90% RH |
| Mechanical Specifications | |
| Dimensions | 440 (W) x 210 (D) 44 (H) mm |
| Weight | 2.67 kg |
| Power Source | |
| AC Input | 100V ~ 240V |
| Frequency | 50 ~ 60 Hz |
Power Consumption | 280W |
| Certifications | |
| Certifications | CE, FCC, LVD, VCCI |
| Warranty | |
| Warranty | 24 months |
| Accessories | |
Included Accessories | Power Cord, QIG, Rack Mount Kit |
