Hanwha - SMT-3231PV - 32” (31.55") AI Enabled IP public view monitor (AI PVM), PIP/PBP, 1080p (1920x1080 60Hz), 16:9 Aspect Ratio, HDMI In (x2), Ethernet, Built-in Speakers (2W x2), AI Object Classification and Analytics, Face Detection, Motion Activ
SMT-3231PV -> 32” (31.55") AI Enabled IP public view monitor (AI PVM) PIP & PBP support,1080p (1920 x 1080 60Hz), HDMI, Ethernet, 16:9 aspect ratio, Built-in speaker (2x2 W), VESA mountable (100 x 100mm / 200 x 100mm), black casing, AI face & Object detection. Display for visual deterrent, customizable text overlay with pre-configured "recording in progress" OSD 2MP IP camera built-in, 3.06mm fixed lens, (107.7" H and 59.0V), 120dB WDR, H.265/H.264/MJPEG, slide show & live video, micro SD/SDHC/SDXC, bi-directional audio, hallway view mode, portrait and landscape display support, HPoE 802.3bt, DC 24V.
Features:
- AI Enabled IP public view monitor (AI PVM) PIP & PBP support
- 1080p (1920 x 1080 60Hz)
- HDMI, Ethernet
- 16:9 aspect ratio
- Built-in speaker (2x2 W)
- VESA mountable (100 x 100mm / 200 x 100mm)
- black casing
- AI face & Object detection
- Display for visual deterrent, customizable text overlay with pre-configured "recording in progress" OSD
- 2MP IP camera built-in, 3.06mm fixed lens, (107.7" H and 59.0V)
- 120dB WDR
- H.265/H.264/MJPEG
- slide show & live video
- micro SD/SDHC/SDXC
- bi-directional audio
- hallway view mode
- portrait and landscape display support
- HPoE 802.3bt, DC 24V
- ***Power adapter not included***
| Alarm | Alarm I/O | Input 1ea / Output 1ea |
| Network | Ethernet | 1 RJ-45 10/100BASE-T, |
| General | Edge Storage | Micro SD/SDHC/SDXC 1slot 256GB |
| On Screen Display | ||
| Functions | VESA™ DPM Compatible | |
| Language | English, Spanish, French | |
| General | ||
| Electrical | Input Voltage | DC24V, HPOE 802.3bt |
| Power Consumption | 56W | |
| Environmental | Operating Temperature | 0 ~ +40°C (+32°F ~ +104°F) |
| Operating Humidity | 10% ~ 80% (non-condensing) |
| Display | ||
| Type | LED Monitor | |
| Screen Size | 31.55" | |
| Max. Resolution | 1920*1080 60Hz (FHD) | |
| Brightness | 400 cd/m² | |
| Contrast Ratio | 1300:1 | |
| Aspect Ratio | 16:9 | |
| Viewing Angle (H/V) | 178°/178° | |
| Display Color | 16.7M Colors | |
| Response Time | 25ms | |
| Panel Life | 30,000 hours | |
| Interface | ||
| Video | Connectors | Camera(Internal, PIP/PBP), HDMI#1(PIP/PBP), HDMI#2 * two windows PIP/PBP : Internal Camera and HDMI#1 |
| Network | Application Programming Interface | ONVIF Profile S/G/T/M SUNAPI(HTTP API) |
| General | Memory | 2GB RAM, 1GB Flash |
| Mechanical | Dimensions without Stand (WxHxD) | 734mm(W) x 490mm(H) x 68mm(D) |
| Weight | 12.4kg | |
| Cabinet Color | Black | |
| VESA Mounts Interface | VESA 100 x 100mm, 200 x 100mm, 200 x 200mm | |
| Camera | ||
| Video | Imaging Device | 1/2.8" 2MP CMOS |
| Max. Framerate | H.265/H.264: Max. 30fps/25fps(60Hz/50Hz) MJPEG: Max. 15fps/12fps(60Hz/50Hz) | |
| Min. Illumination | Color: 0.03Lux (F1.6, 1/30sec) | |
| Lens | Focal Length (Zoom Ratio) | 3.06mm fixed focal |
| Max. Aperture Ratio | F1.6 | |
| Angular Field of View | H: 107.7° / V: 59.0° / D: 126.7° | |
| Operational | Backlight Compensation | BLC, WDR, SSDR |
| Wide Dynamic Range | 120dB | |
| Digital Noise Reduction | SSNRⅤ, WiseNRⅡ(Based on AI engine) | |
| Motion Detection | 8ea, 8point Polygonal zones | |
| Privacy Masking | 32ea, 4point Quadrangle zones | |
| Gain Control | Low / Middle / High | |
| White Balance | ATW / AWC / Manual / Indoor / Outdoor | |
| LDC | Support | |
| Electronic Shutter Speed | Minimum / Maximum / Anti flicker (1/5~1/12,000sec) | |
| Digital PTZ | Support | |
| Video Rotation | Flip, Mirror, Hallway view(90 /270 ) | |
| Analytics | Classified object type: Person/Face Attributes: Not support Support DetectionShot Analytics events based on AI engine - Motion detection, Object detection, Virtualline(Crossing/Direction), Virtual area(Loitering/Intrusion/Enter/Exit) Analytics events - Defocus detection, Tampering, Virtualarea(Appear/Disappear) | |
| Business Intelligence | People counting, Queue management, Heatmap based on AI engine |
