Wi-Tek 2.5G Ethernet Switches provide an easy way to expand your wired network. With all ports support AutoMDI/MDIX, there's no need to worry about the type of cable to use. Featuring full duplex mode can send and receive data at a rate up to 2500Mbps, making it an ideal choice for super-fast connections in LAN parties, home entertainment, home and business offices, and instant transfer for the workstation
2.5G Ports:
Equipped with 2.5GBASE-T RJ-45 ports that provide higher gigabit speeds capable of up to 2.5Gbps over existing Cat5e or better cabling.
Easy Installation:
No configuration needed, simply connect network devices to the 2.5G Ethernet switch.
Fanless:
Fanless design lowers energy consumption and eliminates operating noise
Wall Mountable:
Wi-Tek 2.5G Ethernet Switches are protected by high-quality metal shell to ensure the long service life. They have passed a series of strict tests and provided you with rel iable performance.
Features:
HARDWARE FEATURES | WI-PS505G | |
Interface | 4 100/1000/2500Mbps RJ45 PoE Ports 1 100/1000/2500Mbps RJ45 Ethernet Port | |
PoE Port | Port 1: Hi-PoE 802.3bt 60W Port 2-4: 802.3af/at 30W | |
Network Media | 10BASE-T: Cat3.4.5or more UTP(≤250 m) 100BASE-TX: Cat5e or more UTP(≤150 m) 1000BASE-TX: Cat5e or more UTP(≤150 m) | |
Power Consumption | 65W | |
Ethernet Standard | IEEE 802.3u 100BASEX Ethernet IEEE 802.3ab 1000BASE-T IEEE 802.3bz 2.5GBASE-T | |
Power Supply | DC 52V 1.25A | |
Exchange Capacity | 25Gbps | |
Packet Forwarding Rate | 29.8Mpps | |
Mac Address Table | 16k | |
Packet Buffer Memory | 12Mb | |
Jumbo Frame | 10240 Bytes | |
Protection Level | 6kV ESD Contact discharge 6kV Lightning protection | |
Transmission Method | Store-And-Forward | |
Others | ||
Certification | CE、FCC、RoHS | |
LED Indicator | 1G/2.5Gbps link; 10/100Mbps link; PoE; PWR-Power | |
Package Dimension | 270 220 67 | |
Product Dimension | 223 113 31 | |
Gross Weight | 1.49kg | |
Net Weight | 0.56kg | |
Package Content | 1 × PoE Switch 1 × Power Cord 1 × Power Adapter 1 × Quick Installation Guide | |
Working Environment | Working Temperature: -10~55°C Storage Temperature: -40~80°C Working Humidity: 5%~90%,non-condensing Storage Temperature: 5%~90%,non-condensing | |
