Planet - PWR-480-48 - 48V, 480W Din-Rail Power Supply (NDR-480-48, adjustable 48-56V DC Output)
Product Overview
The Planet PWR-480-48 is a 48V 480W industrial DIN-rail power supply based on the MEAN WELL SDR-480-48 platform, providing 10A output with an adjustable 48–56V DC range. It supports universal 100–240V AC or 127–370V DC input and is certified to UL508, UL60950-1, and TUV EN60950-1 standards. Designed for TS-35/7.5 or TS-35/15 DIN-rail mounting.
Key Configuration
• Output: 48V DC (adjustable 48-56V), rated current 10A, rated power 480W
• Input: 100-240V AC (50/60Hz, 4.8A) or 127-370V DC
• Dimensions: 85.5 × 128.5 × 125.2 mm (W×D×H)
• Weight: 1.6 kg
• Installation: DIN rail TS-35/7.5 or 15
• Safety approvals: UL508, UL60950-1, TUV EN60950-1
Key Features
480W industrial DIN-rail power supply delivering 48V DC at 10A with an adjustable 48–56V output range, suitable for PoE systems. It supports universal 100–240V AC and 127–370V DC input for global and backup power applications. Includes short-circuit, overload, over-voltage, and over-temperature protection, with a slim TS-35 DIN-rail mount design for industrial cabinets. Certified to UL508, UL60950-1, and TUV EN60950-1 safety standards.
Technical Context
The PWR-480-48 is a high-power DIN-rail supply designed for 48V PoE switches, IP camera systems, and industrial network equipment. Its adjustable 48–56V output supports PoE requirements, while the 480W capacity can power multiple PoE devices such as 48×802.3af, 16×802.3at, or 4×802.3bt loads. Built-in overload protection ensures safe operation under heavy load conditions.
Installation Notes
DIN-rail power supply (TS-35/7.5 or 15) measuring 85.5 × 128.5 × 125.2 mm and weighing 1.6 kg. It operates from -20°C to 70°C with 20–90% non-condensing humidity and supports 100–240V AC or 127–370V DC input. Provides adjustable 48–56V DC output at 10A continuous with potentiometer voltage control, overload auto-recovery, and over-voltage protection. Certified to UL508, UL60950-1, and TUV EN60950-1 standards with proper terminal-based AC/DC wiring and branch circuit protection required.
| Dimensions (W x D x H) | 65 x 100 x 125 mm |
| Weight (kg) | 0.79kg |
| Input Voltage | 100-240V AC, 50/60Hz, 3.3A, 248-370V DC |
| Power Output | 120 watts, 48V, 2.5A |
| Temperature | Operating: -10~60 degrees C Storage: -20~85 degrees C |
| Humidity | Operating: 20 ~ 90% Storage: 10 ~ 95% (non-condensing) |
| Installation | DIN rail TS-35/7.5 or 15 |
| Safety & Function | UL508, UL60950-1, TUV EN60950-1 approved |
| PWR-240-48 (MEAN WELL/DR-240-48) | |
| Dimensions (W x D x H) | 125 x 100 x 125 mm |
| Weight (kg) | 1.2kg |
| Input Voltage | 100-240V AC, 50/60Hz, 3.5A, 120-370V DC |
| Power Output | 240 watts, 48V , 5A |
| Temperature | Operating: -10~70 degrees C Storage: -20~85 degrees C |
| Humidity | Operating: 20 ~ 90% Storage: 10 ~ 95% (non-condensing) |
| Installation | DIN rail TS-35/7.5 or 15 |
| Safety & Function | UL508, UL60950-1, TUV EN60950-1 approved |
| PWR-480-48 (MEAN WELL/SDR-480-48) | |
| Dimensions (W x D x H) | 85.5 x 128.5 x 125.2 mm |
| Weight (kg) | 1.6kg |
| Input Voltage | 100-240V AC, 50/60Hz, 4.8A, 127-370V DC |
| Power Output | 480 watts, 48V , 10A |
| Temperature | Operating: -20~70 degrees C Storage: -25~85 degrees C |
| Humidity | Operating: 20 ~ 90% Storage: 10 ~ 95% (non-condensing) |
| Installation | DIN rail TS-35/7.5 or 15 |
| Safety & Function | UL508, UL60950-1, TUV EN60950-1 approved |
