Vivotek - AW-GEL-285A-380 - 4xGE bt 90W PoE+20xGE 30WPoE+2xGE UTP+2xGE SFP LiteManSwitch
Part number:
AW-GEL-285A-380
Price:
4xGE bt 90W PoE+20xGE 30WPoE+2xGE UTP+2xGE SFP LiteManSwitch. 28 Ports Lite Managed PoE Switch.
Features:
- Gigabit Ethernet
- 802.3 at/bt Hybrid
- Extend PoE 250M
| Technical Specification | |
| Product Information | |
| Segment | Lite Managed PoE Switch |
| Product Description | 4xGbE bt 90W PoE + 20xGbE PoE + 2xGbE RJ45 + 2xGbE SFP Lite Managed Switch |
| Port Configuration | |
| PoE Port Ethernet | 24xGbE PoE |
| Uplink Port Ethernet | 2xGbE RJ45 + 2xGbE SFP |
| Total Ports | 28 |
| PoE Function | |
| PoE Port | 24 |
| Max. PoE Output Power | Port 1-4 bt 90W, Port 5-24 at 30W |
| PoE Power Budget | 380W |
| PoE Standard | 802.3 af/at/bt |
| PoE Pin Assignment | Port 1-4 bt: 4 pairs 1/2 (+), 3/6 (-) and 4/5 (+), 7/8 (-) Port 5-24 af/at: 2 pairs 1/2 (+) 3/6 (-) |
| Surge Protection | 4KV |
| HW Performance | |
| Switching Bandwidth | 56 Gbps |
| Buffer Memory | 4.1Mb |
| Forwarding Rate | 38.688 Mpps |
| MAC Address | 8K |
| Jumbo Frames | 9216 Bytes |
| Max. Power Consumption | 390W |
| L2 Managed Features | |
| Spanning Tree | |
| IEEE802.1D (STP) | Yes |
| IEEE802.1w (RSTP) | Yes |
| Trunking | |
| IEEE802.1d (LACP) | Yes |
| Static Aggregation | Yes |
| VLAN | |
| 802.1Q Tag-based VLAN | 4096 VLAN IDs |
| Port-based VLAN | Yes |
| QoS Features | |
| Hardware Queues | 8 |
| Classification | |
| Port Based | Yes |
| 802.1p | Yes |
| Rate Limiting | |
| Ingress | Yes |
| Egress | Yes |
| Per Port | Yes |
| Priority Queue Scheduling | |
| WRR | Yes |
| DSCP & Class of Service | Yes |
| Management | |
| Port Mirroring | Yes |
| Firmware Upgrade | Yes |
| PoE Management | |
| PoE On/Off Control | Yes |
| PoE Alive Checking for PD | Yes |
| Non-Stop PoE | Yes |
| Extended PoE Mode (up to 250m/10mbps) | Yes |
| Environmental Specifications | |
| Operating Temperature | -10°C ~ 50°C (14°F ~ 122°F) |
| Storage Temperature | -20°C ~ 70°C (-4°F ~ 158°F) |
| Operating Humidity | 10 ~ 90% RH |
| Mechanical Specifications | |
| Dimensions | 442 (W) x 212 (D) 44 (H) mm |
| Weight | 2.74 kg |
| Power Source | |
| Power Input | 100V ~ 240V |
| Frequency | 50 ~ 60 Hz |
| Certifications | |
| Types | CE, FCC, UKCA, LVD, VCCI, BSMI |
| Included Accessories | |
| Content | Power Cord, QIG Rack Mount Kit |
