Hanwha - SPO-6011 - 60W HPoE Injector, Fully compliant with IEEE802.3af/at/bt, PoE++, Built-in SFP slot, Compatible with XNP-9250R / XNP-8250R / XNP-6400R / TNB-9000
Part number:
SPO-6011
Price:
The SPO-6011 injects Power over data-carrying Ethernet cabling. It follows the IEEE802.3BT/IEEE802.3AT/IEEE802.3AF standards and is compatible with existing Ethernet switches and networked devices. Injector provides up to 60W HPoE/POE++, Built-in SFP slot. Compatible with XNP-9250R / XNP-8250R / XNP-6400R / TNB-9000
| Input & Output | |
| Input | 100-240Vac 2.0A 50/60Hz |
| Output | 55Vdc 1100mA |
| Power Pins | 4/5(+), 7/8(-) and 3/6(+),1/2(-) |
| Data Speed | 10/100/1000BASE-T RJ45 Interfaces 1000BASE-X SFP Interfaces |
| Working Environment | |
| Operating Temperature | -40℃ to 55℃ |
| Operating Humidity | 20% to 90%, non-condensation |
| Storage Temperature | -40℃ to +85℃ |
| Storage Humidity | 10% to 90%, non-condensation |
| Operating Altitude | up to 10,000 ft |
| LED Indicator | |
| Power indicator | Green |
| Load active Indicator | Green |
| SFP fiber indicator | Green |
| LAN data indicator | Yellow |
| PoE data indicator | Yellow |
| Safety Approval | |
| cUL/UL, KC, RCM, NOM, BSMI, CE, SAA, PSB, SII, EAC, FCC, ST, CCC, Ukrain, BIS, PSE, CM, LOA, CB, UKCA | |
| Mechanical Characteristics | |
| Case | Plastic |
| Color | Black |
| Mounting | Wall-mounted |
| IP Rated | IP40 |
| Size | 218 x 85 x 41mm |
| Weight | 480g |
