TRENDNET - TEG-S83 - 8-Port Gigabit Switch /w metal case

Name: TRENDNET - TEG-S83 - 8-Port Gigabit Switch /w metal case
Brand: Trendnet
SKU: TEG-S83

Part number:

TEG-S83

Price:

Dealers only

Add to Quote/Project Registration

Description Specifications Downloads

The 8-Port Gigabit Desktop Switch, model TEG-S83, provides high-bandwidth performance, ease of use, and reliability. This gigabit switch boosts office network efficiency and eliminates network congestion. It features gigabit speeds and a total switching capacity of 16Gbps with full-duplex mode. Integrate this sturdy metal gigabit switch for reliable high-speed network connectivity.

Features:

Plug and play installation
8 x Gigabit ports
16Gbps switching capacity
Sturdy metal switch
Fanless design
NDAA / TAA compliant (U.S. and Canada only)
Lifetime Warranty

Standards	IEEE 802.3 IEEE 802.3u IEEE 802.3x IEEE 802.3ab
Device Interface	8 x Gigabit ports LED indicators
Data Transfer Rate	Ethernet: 10Mbps (half duplex), 20Mbps (full duplex) Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex) Gigabit: 2000Mbps (full duplex)
Performance	Switching Capacity: 16Gbps RAM Buffer: 192KB MAC Address Table: 4K entries Forwarding Rate: 11.9Mpps (64-byte packet size) Jumbo Frames: 9KB
Power	Input: 100 – 240V AC, 50/60 Hz, 0.2A Output: 5 V DC, 1A external power adapter Max. Consumption: 3.2W
Fan/Acoustics	Fanless design
MTBF	1,451,740 hours
Operating Temperature	0° – 40° C (32° – 104° F)
Operating Humidity	Max. 90% non-condensing
Dimensions (L x W x H)	160 x 25 x 109mm (6.29 x 0.98 x 4.29 in.)
Weight	414g (14.6 oz.)
Certifications	FCC CE
Warranty	Lifetime Warranty*

PACKAGE CONTENTS

TEG-S83
Quick Installation Guide
Power Adapter (5V DC, 1A)

Name

Description

Size

Downloads

File

Datasheet

0.7mb
