TRENDNET - TEG-S82g - 8-port Gigabit GREENnet Switch /w metal case
Part number:
TEG-S82g
Price:

The 8-Port Gigabit GREENnet Switch, model TEG-S82g, provides high bandwidth performance, ease of use, and reliability, all while reducing power consumption by up to 70%*. GREENnet technology automatically adjusts power consumption as needed, resulting in substantial energy savings. Embedded GREENnet technology works right out of the box with no management requirement.



Boost office network efficiency and eliminate network congestion with gigabit speeds and a total switching capacity of 16Gbps with full-duplex mode. Integrate this sturdy metal switch for reliable high speed network connectivity.



Features:

  • Plug and play installation
  • 8 x Gigabit ports
  • 16Gbps switching capacity
  • Up to 70% energy savings with GREENnet technology*
  • Wall mountable metal housing
  • NDAA / TAA compliant (U.S. and Canada only)
  • Lifetime Warranty
Standards
  • IEEE 802.3
  • IEEE 802.3u
  • IEEE 802.3x
  • IEEE 802.3ab
  • IEEE 802.3az
Device Interface
  • 8 x Gigabit ports
  • LED indicators
Data Transfer Rate
  • Ethernet: 10Mbps (half duplex), 20Mbps (full duplex)
  • Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex)
  • Gigabit: 2000Mbps (full duplex)
Performance
  • Data RAM buffer: 192KB
  • Switch fabric: 16Gbps
  • MAC address table: 4K
  • Forwarding rate: 11.9Mpps (64-byte packet size)
  • Jumbo frame: 9KB
Special Features
  • GREENnet energy saving technology
  • Metal enclosure
  • Wall Mountable
Power
  • Input: 100 – 240V AC, 50/60Hz, 0.15A
  • Output: 5V DC, 1A external power adapter
  • Max. consumption: 4W
Fan/Acoustics
  • Fanless design
MTBF
  • 2,082,116 Hours
Operating Temperature
  • 0° – 40° C (32° – 104° F)
Operating Humidity
  • Max. 90% non-condensing
Dimensions
  • 150 x 97 x 28mm (5.9 x 3.8 x 1.1 in.)
Weight
  • 365g (12.9 oz.)
Certifications
  • CE
  • FCC
Warranty
  • Lifetime Warranty*

PACKAGE CONTENTS

  • TEG-S82g
  • Quick Installation Guide
  • Power adapter (5V DC, 1A)
Name
Description
Size
Downloads
File
Datasheet
1.6mb
