Hanwha - SPO-8315 - 83W HPoE Injector, Fully compliant with IEEE802.3af/at/bt, PoE++, Built-in SFP slot, Compatible with XNP-9300RW / XNP-8300RW / XNP-6400RW, PNM-9085RQZ / PNM-9085RQZ1 / PNM-9084RQZ / PNM-9084RQZ1 / PNM-9322VQP / SMT-3221PV / SMT-32
Part number:
SPO-8315
Price:
The SPO-8315 injects Power over data-carrying Ethernet cabling. It follows the IEEE802.3BT/IEEE802.3AT/IEEE802.3AF standards and is compatible with existing Ethernet switches and networked devices. Injector provides up to 83W HPoE/POE++, Built-in SFP slot. Compatible with XNP-9300RW / XNP-8300RW / XNP-6400RW, PNM-9085RQZ / PNM-9084RQZ / PNM-9085RQZ1 / PNM-9084RQZ1 / PNM-9320VQP / PNM-9321VQP / PNM-9322VQP / PNM-C344004RQPZ
Features:
- 83W / 1.5A HPoE injector
- SFP port included
| Input & Output | |
| Input | 100-240Vac 2.0A 50/60Hz |
| Output | 55Vdc 1500mA |
| Power Pins | 4/5(+), 7/8(-) and 3/6(+),1/2(-) |
| Data Speed | 10/100/1000BASE-T RJ45 Interfaces 1000BASE-X SFP Interfaces |
| Working Environment | |
| Operating Temperature | -40℃ to 65℃ |
| Operating Humidity | 20% to 90%, non-condensation |
| Storage Temperature | -40℃ to +85℃ |
| Storage Humidity | 10% to 90%, non-condensation |
| Operating Altitude | up to 10,000 ft |
| LED Indicator | |
| Power indicator | Green |
| Load active Indicator | Green |
| SFP fiber indicator | Green |
| LAN data indicator | Yellow |
| PoE data indicator | Yellow |
| Safety Approval | |
| cUL/UL, KC, RCM, NOM, BSMI, CE, SAA, PSB, SII, EAC, FCC, ST, CCC, Ukrain, BIS, PSE, CM, LOA, CB, UKCA | |
| Mechanical Characteristics | |
| Case | Metal |
| Color | Black |
| Mounting | Wall-mounted |
| IP Rated | IP20 |
| Size | 213.9 x 134 x 41mm |
| Weight | 1104g |
