- • 2560 x 1920 Resolution at 30 fps
- • IR LEDs for Night Vision up to 66'
- • 1.05mm Fixed Fisheye Lens
- • 180° Horizontal Angle of View
- • Two-Way Audio
- • RJ45 Ethernet with PoE Technology
| Key Specs | |
|---|---|
| Image Sensor | 1/2.7"-Type CMOS |
| Focal Length | 1.05mm |
| Field of View | Horizontal: 180° Vertical: 180° |
| Built-In Microphone | Yes |
| Power I/O | 1x DC (12VDC) 1x RJ45 |
| Imaging | |
| Number of Lenses | 1 |
| Image Sensor | 1/2.7"-Type CMOS |
| Sensor Resolution | Effective: 5 Megapixel |
| IR Cut Filter | Yes Mechanical |
| Day/Night | Yes |
| Exposure Control | |
| Shutter Speed | 1/100000 to 1/3 Second |
| Automatic Gain Control | Yes |
| Signal-to-Noise Ratio | 75 dB |
| Minimum Illumination | 0.017 Lux (Color) 0 Lux (Black and White) |
| Lens | |
| Focal Length | 1.05mm |
| Field of View | Horizontal: 180° Vertical: 180° |
| Maximum Aperture | f/2.25 |
| Video | |
| Max IP Streaming | H.264, H.264+, H.265, H.265+ via RJ45 2560 x 1920 up to 30.00 fps |
| Multi-View Streaming | Yes: 2 Streams |
| Control | |
| Supported Control Protocols | RS-485 |
| Networking | |
| Security | HTTPS, IP Address Filtering, Password Protection |
| Interface | |
| Other I/O | 1x RJ45 1x 9-Pin (RS-485, Serial) |
| 1- or 2-Way Audio | Two-Way |
| Audio Formats | AAC, G.711, G.722.1, G.726, MP2L2, MP3, PCM |
| Built-In Microphone | Yes |
| System Integration | |
| Analytics | Audio Detection, Camera Sabotage/Tampering, Heat Mapping, Motion Detection, People Counting |
| Sensors & Alarms | |
| Event Trigger | Yes |
| Event Action | Recording, Notification, Alarm |
| Alarm I/O | No |
| Power | |
| PoE Support | PoE 802.3af |
| Power I/O | 1x DC (12VDC) 1x RJ45 |
| Power Consumption | 12 VDC 6 W PoE: 7.5 W |
| Environmental | |
| Operating Conditions | -14 to 122°F / -25 to 50°C up to 95% Humidity |
| General | |
| Certifications | CE, FCC |
| Illumination | 4x 850 nm IR LEDs up to 65.6' / 20 m |
| Dimensions (W x H x D) | 4.7 x 1.6 x 4.7" / 119.9 x 41.2 x 119.9 mm |
| Weight | 0.7 lb / 320 g (Body Only) |
