- • 5 Megapixel, 33x, PTZ
- • Deep Learning AI, ColorGuard
- • IR LED 250m, Extreme WDR (150 dB)
- • White LED 100m, Smart Dual Light, Color Min. Illumination 0.002 lux
- • Frame Rate 60fps
- • Two-way Audio
- • PTZ Auto Tracking, 360° endless
- • Smart Motion Detection, Smart Intrusion Protection
- • Weatherproof (IP66), Vandal proof (IK10)
- • DI/DO
| Product Profile | |
|---|---|
| Product Type | PTZ |
| Application Environment | Outdoor |
| Maximum Resolution | 5MP |
| Image Sensor | Progressive Scan CMOS |
| Sensor Size | 1/2.7 " |
| Effective Pixels | 2608(H) X 1964(V) (5.1 MP) |
| Day / Night | Yes |
| Low Light Sensitivity | Extreme |
| ColorGuard | Yes |
| Minimum Illumination | Color: 0.002 lux at F1.5 (AGC on); B/W: 1 lux at F1.5 (AGC on); 0 lux (IR LED on) |
| Mechanical IR Cut Filter | Yes |
| IR LED | Adaptive IR LED |
| IR Working Distance | 250m |
| White LED | Yes |
| White LED Working Distance | 100m |
| Smart Dual Light | Yes |
| Electronic Shutter | 1-1/30000 second (manual mode); 1-1/30000 second (auto mode) |
| S/N Ratio | 75 dB |
| Lens | |
| Focal Length | Zoom, f5.9-194.7mm |
| Aperture | F1.5 |
| Zoom Ratio | 33x optical zoom, 16x digital zoom |
| Zoom Speed | 5.6 second (wide to tele) |
| Zoom Application | Camera Installation, Manual Operation, Auto Zoom by Event |
| Horizontal Viewing Angle | 60.2° - 2.3° |
| Vertical Viewing Angle | 35.2° - 1.3° |
| PTZ | |
| Manual Panning / Tilting Speed | 0.1° - 160°/second, 0.1° - 120°/second |
| Preset Panning / Tilting Speed | 240°/second, 200°/second |
| Panning Range | 360° endless |
| Tilting Range | -15°~90° (with E-flip) |
| PTZ Control | 300 preset points |
| Video | |
| Compression | H.265 Adaptive Stream (equivalent to Zip or Smart Stream or H.265+), H.264 Adaptive Stream (equivalent to Zip or Smart Stream or H.264+), MJPEG |
| Maximum Frame Rate vs. Resolution | 30 fps at 2592 x 1944 30 fps at 2688 x 1520 30 fps at 2560 x 1440 60 fps at 1920 x 1080 (High Frame Mode) 30 fps at 1280 x 960 60 fps at 1280 x 720 (High Frame Mode) 30 fps at 704 x 480 30 fps at 640 x 480 30 fps at 352 x 240 |
| Multi-Streaming | Simultaneous quad streams |
| Digital Noise Reduction | 3D DNR |
| Wide Dynamic Range | Extreme WDR (150 dB) |
| Image Enhancement | White Balance, Brightness, Contrast, Sharpness, Automatic gain control (AGC), Backlight compensation (BLC), Highlight compensation (HLC), Digital Image Stabilizer (DIS, EIS), Defogging |
| Privacy Mask | 24 configurable regions |
| Built-in Analytics | Smart Motion Detection (People Detection, Vehicle Detection), Smart Intrusion Protection (People Line Crossing Detection, People Intrusion Detection, People Enter Area Detection, People Exit Area Detection, Vehicle Line Crossing Detection, Vehicle Intrusion Detection, Vehicle Enter Area Detection, Vehicle Exit Area Detection), Missing Object Detection, Unattended Object Detection, Tampering Detection, PTZ Auto Tracking |
| Analytics | |
| Deep Learning AI | 1.0 |
| Audio | |
| Audio Type | 2-way, Line-in, Line-out |
| Audio Compression | G.711, G.722.1, G.726, MP2L2, PCM, AAC-LC, MP3 |
| Network | |
| Network Protocol & Service | IPv4/v6, Bonjour, DDNS, DNS, DHCP, FTP, HTTP, HTTPS, ICMP, IEEE 802.1X, IGMP, NTP, PPPoE, QoS, RSTP, RTCP, RTMP, RTP, SMTP, SNMP, TCP, IP, UDP, UPnP |
| Ethernet Port | 1, Ethernet (10/100 Base-T), RJ-45 connector |
| Maximum User Connections | 32 |
| Security | HTTPS encryption, IEEE 802.1X network access control, IP address filtering, Password protected user level |
| Integration | |
| ONVIF Compliant | Yes, Profile S, Profile G, Profile T |
| Web Browser | IE 11, Google Chrome, Firefox, Apple Safari |
| Interface | |
| Audio Interface | Built-in Speaker, 1/1, Terminal block |
| Digital Input/Output | 2/1 |
| Operating Button | Reset Button |
| General | |
| Power Source | High PoE (IEEE802.3at), DC 36V |
| Power Consumption | Max. 42 W (PoE, heater and IR on) |
| Weight | 5500g (12.13lb) |
| Dimensions | (Ø x H): Outdoor: 220mm x 360.2mm (8.7" x 14.2") |
| Environmental Casing | Vandal proof (IK10), Weatherproof (IP66) |
| Bundled Accessories | Power Adapter (DC 36V) |
| Heater | Yes |
| Operating Temperature | -30°C ~ 65°C (-22°F ~ 149°F) |
| Operating Humidity | ≤90% RH, non-condensing |
| Surge Protection | 6KV |
| Approvals | CE, FCC, IP66, IK10 |
| Color | White |
| Real-time Clock (RTC) | Yes |
