ACTi - BCS-100 - BCS-100 100-Channel 1-Bay Standalone Broadcast System
Part number:
BCS-100
Price:
Features:
● Ability to get video stream from NVR via RTSP and duplicate video stream to multiple clients
● Support 50-channel video source with 4CIF/15fps, and broadcast 200-channel video output with 4CIF/15fps
● Support video stream incoming and outgoing with H.264/15fps for single channel
| CPU | Intel Core i5-6500TE |
| RAM | 8GB |
| License required | Yes |
| Free License | 4 |
| Audio Type | 2-way, Mic-in, Line-out |
| Ethernet Port | 2 x Ethernet (1000 Base-T), RJ-45 connector |
| Server Operating System | Windows 10 IoT |
| USB | 6-Port USB 3.0 |
| System Drive | SSD, 128GB |
| Storage Bay | SATA, Max. 1 Disk(s) (without storage disks) |
| HDD Size | 3.5" |
| Serial Port | 2 x RS-232 |
| Audio Interface | 1/1, 3.5mm Phone Jack |
| External Storage Interface | eSATA, iSCSI, USB |
| Local Access | USB keyboard & mouse |
| Local Display Interface | HDMI x 1, DVI x 1, Display Port x 1 |
| Power Source | AC 100-240V |
| Dimensions | (W x H x D): 255mm x 88mm x 230mm (10" x 3.5" x 9.1") |
| Bundled Accessories | Power cord |
| Fan | Yes |
| Operating Temperature | 0°C ~ 40°C (32°F ~ 104°F) |
| Operating Humidity | 10% - 85% RH |
| Approvals | CE, FCC, UL (for built-in power adapter) |
| Warranty | 3 Year(s). For extended warranty offering, see http://www.acti.com/support/warranty |
Name
Description
Size
Downloads
File
Data Sheet
0.1mb
