Acti - PPOE-0002 - PoE Injector IEEE 802.3af compliant, AC 100~240V, with universal connectors
Part number:
PPOE-0002
Price:
PoE Injector IEEE 802.3af compliant, AC 100~240V, with universal connectors
| Device | |
| Product Type | PoE Injector |
| Description | PoE Injector IEEE 802.3af compliant, AC 100~240V, with universal connectors |
| Network | |
| Ethernet Port | (DATA & POWER OUT) PoE: 1 port(s), Ethernet (10/100/1000 Base-T), RJ-45 connector (DATA IN) 1 x RJ-45 |
| connector Network Cable: | TIA/EIA-568, Category 5/5e/6, 2/4-pair cables |
| General | |
| PoE Standard | IEEE 802.3af |
| PoE Output | Maximum 15.4 Watts per port |
| Power Output | DC 48V, 0.4A |
| Power Source | AC 100-240V |
| Dimensions (W x H x D): | 73mm x 24mm x 55mm (2.88" x 0.94" x 2.17") |
| Operating Temperature | 0°C ~ 50°C (32°F ~ 122°F) |
| Warranty | 1 Year(s) |
Name
Description
Size
Downloads
File
Datasheet
0.9mb
