Acti - PPOE-0104 - High PoE injector Single-port, 60W Gigabit Midspan, 4-Pairs, 802.3at Compliant
Part number:
PPOE-0104
Price:
High PoE Injector, Single-port,10/100/1000Mbps 60W, 4-Pairs, 802.3at Compliant, AC 100~240V, with universal connectors (for, I93~I910, I915, B915~B917, B922, B928, B945, B949, A950,A951)
| Device | |
| Product Type | PoE Injector |
| Description | High PoE injector Single-port, 60W Gigabit Midspan, 4-Pairs, 802.3at Compliant, AC 100~240V, with universal connectors (for I93~I910, I915, B915~B917, B922, B928, B945, B949, A950, A951, A952, A956) |
| Network | |
| Ethernet Port | (DATA & POWER OUT) PoE: 1 port(s), Ethernet (10/100/1000 Base-T), RJ-45 connector (DATA IN) 1 x RJ-45 connector Network Cable: 4-pair UTP Category 5/53/6, 2-pair UTP Category 3/4/5, up to 100m (328ft) |
| General | |
| PoE Standard | IEEE 802.3at |
| PoE Output | Maximum 60 Watts (4-pair) Maximum 30 Watts (2-pair) |
| Power Output | DC 56V |
| Power Source | AC 100-240V |
| Weight | 246g (0.54lb) |
| Dimensions | (W x H x D): 115mm x 31mm x 62.5mm (4.53" x 1.22" x 2.46") |
| Operating Temperature | 0°C ~ 50°C (32°F ~ 122°F) |
| Warranty | 1 Year(s) |
