ACTi - PPSW-0105 - 8-Port Gigabit 802.3at Managed PoE Switch (PoE Budget 120W)
Part number:
PPSW-0105
Price:
GS-4210-8P2C 8-Port Gigabit 802.3at Managed PoE Switch (PoE Budget 120W).
Features:
- Rack Space: 1U
| Device | |
| Original Manufacturer | PLANET |
| Product Type | Data Switch |
| Original Model | GS-4210-8P2C |
| Description | 8-Port Gigabit 802.3at Managed PoE Switch (PoE Budget 120W) |
| Network |
| Network Protocol & Service | IPv4/v6, STP, RSTP, MSTP, IGMP, IEEE 802.1P, IEEE 802.1Q, IEEE 802.1X, SNMP, SSH, SSL/TLS |
| Ethernet Port | PoE: 8 port(s), Ethernet (10/100/1000 Base-T), RJ-45 connector Non-PoE: 2 port(s), Ethernet (10/100/1000 Base-T), RJ-45 connector 2 x Ethernet (100/1000 Base-X), SFP connector |
| General |
| PoE Standard | IEEE 802.3af, IEEE 802.3at |
| PoE Output | Maximum 30 Watts per port |
| PoE Power Budget | Maximum 120 W |
| Power Source | AC 100-240V |
| Weight | 1732g (3.82lb) |
| Dimensions | (W x H x D): 280mm x 44mm x 180mm (11.02" x 1.73" x 7.09") Rack Space: 1U |
| Operating Temperature | 0°C ~ 50°C (32°F ~ 122°F) |
| Storage Temperature | -20 °C ~ 70 °C (-4 °F ~ 158 °F) |
| Approvals | CE, FCC Class A |
| Warranty | 1 Year(s) |
Name
Description
Size
Downloads
File
Datasheet
0.7mb
