• Video Access Control Functionality
• Facial Recognition for 6000 Faces
• Built-In MIFARE RFID 13.56 MHz Module
• 50,000 Card & 50,000 Event Capacity
• 2MP Resolution with Dual Lenses
• 7" LCD Touchscreen
• IP65 Rated for Outdoor Use
| Product Profile | |
|---|---|
| Product Type | Reader and Controller |
| Device Type | Access Controller RFID Reader Face Reader |
| Product Application | Access Control with Card + Face Recognition |
| Application Environment | Semi-Outdoor |
| Maximum Resolution | 2MP |
| LCD Screen | 7" Color Touch Screen; Resolution: 600 × 1024 |
| Lens | |
| Number of Lenses | 2 Lenses |
| Video | |
| Built-in Analytics | Face Recognition |
| Network | |
| Ethernet Port | 1 x Ethernet (10/100/1000 Base-T), RJ-45 connector |
| Video Analytics | |
| Face Recognition Distance | 0.3m - 3m |
| Event | |
| Event Log | 150,000 |
| System | |
| Operating System | Linux |
| Access Control Functionality | |
| Access Mode | Card only, Face only, Card and Face |
| RFID Card | |
| RFID Frequency | 13.56 MHz |
| Reading Range | 0-5cm |
| RFID Options | Mifare |
| Storage | |
| User Database | Card Capacity: 50000 Face Picture Capacity: 6000 |
| Face Only Detection User Limit | 6000 |
| Interface | |
| Serial Port | 1 x RS-485 |
| Digital Input/Output | 2/1 |
| Digital Input | Exit Button x 1, Door contact x 1 |
| Relay Output | Door lock x 1 |
| Wiegand Port | Wiegand in/out (configurable) x 1 |
| General | |
| Power Source | DC 12V (adapter not included), 2 A |
| Dimensions | (W x H x D): 110.5mm x 209.2mm x 24mm (4.35" x 8.24" x 0.94") |
| Environmental Casing | Weather resistant (IP65) |
| Operating Temperature | -30°C ~ 60°C (-22°F ~ 140°F) |
| Operating Humidity | 10% - 90% RH, non-condensing |
| Warranty | 1 Year(s). For extended warranty offering, see http://www.acti.com/support/warranty |
