Acti - Z724 - 4MP Deep Learning AI ColorGuard f2.8mm Outdoor Fixed Dome with White LED 40m, ColorVizion, WDR 135dB
Part number:
Price:
- • 4 Megapixel, f2.8mm, Fixed Dome
- • Deep Learning AI, ColorGuard
- • 1/1.8" Sensor, Aperture F1.0, Extreme WDR (135 dB)
- • White LED 40m, Color Min. Illumination 0.0003 lux, ColorVizion
- • Built-in Microphone
- • Smart Motion Detection, Smart Intrusion Protection
- • Weatherproof (IP67), Vandal proof (IK10), UL Listed
| Product Profile | |
|---|---|
| Product Type | Fixed Dome |
| Application Environment | Outdoor |
| Maximum Resolution | 4MP |
| Image Sensor | Progressive Scan CMOS |
| Sensor Size | 1/1.8" |
| Day / Night | Yes |
| Low Light Sensitivity | Superior |
| ColorGuard | Yes |
| ColorVizion | Yes |
| Minimum Illumination | Color: 0.0003 lux at F1.0 (AGC on) |
| Mechanical IR Cut Filter | No |
| IR LED | No |
| White LED | Yes |
| White LED Working Distance | 40m |
| Electronic Shutter | 1-1/100000 second (manual mode); 1-1/100000 second (auto mode) |
| S/N Ratio | 75 dB |
| Lens | |
| Focal Length | Fixed focal, f2.8mm |
| Aperture | F1.0 |
| Iris | Fixed iris |
| Horizontal Viewing Angle | 110.4° |
| Vertical Viewing Angle | 60.5° |
| Viewing Angle Adjustment | Pan: 8°-360°, Tilt: 0°-68°, Rotation: 10°-360° |
| Video | |
| Compression | H.265 Adaptive Stream, H.264 Adaptive Stream, MJPEG |
| Maximum Frame Rate vs. Resolution | 25 fps at 2688 x 1520, 25 fps at 2560 x 1440, 30 fps at 2304 x 1296, 30 fps at 1920 x 1080, 30 fps at 1280 x 720, 30 fps at 720 x 576, 30 fps at 640 x 360, 30 fps at 704 x 288, 30 fps at 352 x 288 |
| Multi-Streaming | Simultaneous dual streams |
| Digital Noise Reduction | 2D + 3D DNR |
| Wide Dynamic Range | Extreme WDR (135 dB) |
| Image Orientation | Flip, Mirror, Rotation (Corridor mode)(±90⁰, 180⁰) |
| Image Enhancement | White Balance, Digital Noise Reduction, Backlight compensation (BLC), Highlight compensation (HLC), Defogging, Brightness, Contrast, Sharpness, Automatic gain control (AGC) |
| Privacy Mask | 4 configurable regions |
| Text Overlay | Yes |
| Built-in Analytics | Smart Motion Detection (People Detection, Vehicle Detection), Smart Intrusion Protection, People Line Crossing Detection, People Intrusion Detection, Vehicle Line Crossing Detection, Vehicle Intrusion Detection, Tampering Detection |
| Analytics | |
| Deep Learning AI | 1.0 |
| Audio | |
| Audio Type | 1-way, Built-in Microphone |
| Audio Compression | G.711 |
| Network | |
| Network Protocol & Service | IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTSP, DNS, DDNS, NTP, UPnP, HTTP, HTTPS, SMTP, SNMP, QoS |
| Ethernet Port | 1, Ethernet (10/100 Base-T), RJ-45 connector |
| Maximum User Connections | 32 |
| Security | HTTPS encryption, Password protected user level, IP address filtering |
| Event | |
| Event Trigger | Video motion detection, Tampering detection, Sound detection, Intelligent event detection |
| Integration | |
| ONVIF Compliant | Profile S, Profile G, Profile T |
| Web Browser | IE 11 or newer, Google Chrome, Microsoft Edge, Firefox |
| Interface | |
| Operating Button | Reset Button |
| General | |
| Power Source | DC 12V, PoE (IEEE802.3af) |
| Power Consumption | 4 W (PoE) |
| Weight | 530g (1.16lb) |
| Dimensions (Ø x H) | 128mm x 100mm (5.0" x 3.9") |
| Environmental Casing | Weatherproof (IP67), Vandal proof (IK10) |
| Operating Temperature | -30°C ~ 60°C (-22°F ~ 140°F) |
| Storage Temperature | -30°C ~ 60°C (-22°F ~ 140°F) |
| Operating Humidity | ≤95% RH, non-condensing |
| Surge Protection | 4KV |
| Approvals | CE Class B, FCC Class B, IP67, IK10, UL Listed |
| Material | Metal, Plastic |
| Real-time Clock (RTC) | No |
| Warranty | 2 Year(s) |
