AVTech - DGM8209SVAT - 12MP Omni Multi-Sensor Dome IP Camera
The AVTech 12MP/20MP Compact IP Series delivers high-resolution surveillance in an ultra-discreet, low-profile form factor. Engineered for versatility, it features remote focus, a 3-axis gimbal, and interchangeable lens options 2.1–16mm. Optimized for challenging lighting, the series includes 100dB Enhanced WDR, True Day/Night, and SNAPstream™ technology for maximum bandwidth efficiency. The rugged IP66/IK-10 housing ensures reliable performance in extreme outdoor environments.
Key Configuration
- • Resolution options: 12MP and 20MP models
- • Lens: M12 with remote focus module; multiple lens options from 2.1mm to 16mm
- • Gimbal: 3-axis with 360° pan, 90° tilt, and 360° z-axis
- • Compression: dual encoder H.264/MJPEG with 21 quality levels
- • Power: PoE (IEEE 802.3af, Class 3) or auxiliary 18–48V DC / 24V AC; max power 14W (auxiliary)
Key Features
The AVTech Compact IP Series delivers high-resolution forensic imaging optimized for any environment. It features MoonLight™ Mode for superior low-light performance and 120dB WDR for high-contrast clarity. With Forensic Zooming and Picture-in-Picture, it replaces traditional PTZ units by capturing zoomed details without losing the full field of view. Enhanced with SNAPstream™ for bandwidth efficiency and 1024-zone motion detection, this series provides intelligent, high-fidelity surveillance in a streamlined package.
Technical Context
• Network protocols: HTTP, IPv4, 802.1x, RTSP, RTP/TCP, RTP/UDP, TFTP, DHCP.
• Network interface: 100Base-T Ethernet.
• Multi-streaming: 8 non-identical streams. ONVIF Profile S conformant.
• Electrical: alarm input/output 1 input / 1 output.
• Complete mounting options available.
Installation Notes
This Made in the USA ultra-discreet, low-profile housing is engineered for peak performance in demanding environments. Featuring an IP66-rated and IK10 impact-resistant chassis, it thrives in extreme temperatures ranging from -40°C to +50°C. This compact unit (Ø7.7" x 3.1") is fully compliant with UL, FCC Class A, CE, RoHS, and REACH standards, providing a rugged, high-reliability solution for professional outdoor installations.
| Programmability | |
|---|---|
| Optics | M12 lens and remote focus module |
| Low Light Performance | Pixel Binning Mode |
| Picture-in-Picture | Simultaneous delivery of full field-of-view and zoomed images |
| Programmable Shutter Speed | Controls motion blur, 1ms – 500ms |
| Motion Detection | Real-time, 1024 detection zones |
| Privacy Masking | Unlimited |
| MoonLight™ Mode | Extended exposure and noise cancellation |
| Flexible Cropping | Resolution windowing down to 1×1 pixel for JPEG and 2×2 pixels for H.264 |
| Backlight Compensation | Auto multi-matrix white balance |
| Flicker Control | 5Hz – 255Hz adjustable |
| Wide Dynamic Range | Auto switch control adjustment between WDR and LDR modes (WDR models) |
| Efficiency | SNAPstream™ (Smart Noise Adaptation and Processing) Bit rate and bandwidth limitation control Bandwidth and storage savings by running at 1/4 resolution |
| Sharpness | Selectable enhancement level |
| Miscellaneous | Programmable resolution, brightness, saturation, gamma, tint Simultaneous delivery of full field-of-view and zoomed images Electronic pan, tilt, zoom (PTZ) Auto Exposure (AE) and Gain Control (AGC) > 120dB Programmable shutter speed to help control motion blur |
| Data Transmission | |
| Compression Type | H.264 (MPEG-4, Part 10) / Motion JPEG 21 levels of quality |
| Network Protocols | HTTP, IPv4, 802.1x, RTSP, RTP/TCP, RTP/UDP, TFTP, DHCP |
| Network Interface | 100Base-T Ethernet |
| Multi-Streaming | 8 non-identical streams |
| Compliance & Certifications | |
| Industry Standard | ONVIF Profile S conformant |
| Listings | UL (CB) |
| FCC Compliance | 47 CFR 15 Class A |
| Environmental | RoHS, REACH, WEEE |
| Markings (CE) | EN 55022:2010 Class A, EN 55024:2010, EN 61000-3-2:2006+A1:2009+A2:2009, EN61000-3-3:2008, EN60950-1:2006+A11:2009+A1:2010+A12:2011, (UL) IEC 60950-1 (ed. 2) and IEC 60950-22 (ed. 1) |
| Country of Origin | Made in the USA |
| Environmental | |
| Operating Temperature | -40°C (-40°F) to +50°C (122°F) |
| Humidity | 0% to 90% (non-condensing) |
| Storage Temperature | -40°C (-40°F) to +60°C (140°F) |
| Electrical | |
| Alarm Input/Output | 1 input / 1 output |
| Power Over Ethernet (PoE) | PoE 802.3af, Class 3 |
| Auxiliary Power | 18–48V DC, 24V AC |
| Max Power Consumption | 14W max (auxiliary) |
| Mechanical | |
| Casing | Die-cast aluminum chassis with polycarbonate dome bubble IP66 weather proof standard Impact resistant, IK-10 rated |
| Gimbal | Easily adjustable, 3-axis w/360° pan, 90° tilt, and 360° z-axis |
| Dimensions | |
| Unit (Ø × H) | Ø 7.7" (196 mm) × 3.1" H (78.5 mm) |
| Bubble Only (Ø × H) | Ø 6.7" (169.2 mm) × 1.3" H (33.4 mm) |
| Packaged (W × L × H) | 8" W (203 mm) × 8" L (203 mm) × 4" H (102 mm) |
| Weight | |
| Unit | 2.8 lbs (1.27 kg) |
| Packaged | 3.4 lbs (1.54 kg) |
