AVYCON - ANCP9005GQ - Enterprise Wireless CPE Gigabit Network Bridge
Product Overview
The Avycon ANCP9005GQ is an enterprise wireless CPE gigabit network bridge designed for indoor or outdoor point-to-point network links. It can connect remote IP cameras to existing NVRs or DVRs over a 5.8GHz wireless bridge, supporting long-range deployment up to 3.11 miles with clear line of sight.
Key Configuration
Model: ANCP9005GQ | Product Type: Enterprise Wireless CPE Gigabit Network Bridge | Chipset: Qualcomm Atheros | Wireless Frequency: 5.8GHz | Wireless Speed: Up to 867Mbps | Range: Up to 3.11 miles / 5km Line of Sight | Antennas: Dual 14dBi | Mounting: Pole / Wall / Rack
Key Features
· High-power indoor/outdoor CPE supports long-range wireless network bridging
· Connects remote IP cameras to existing NVR or DVR systems
· Supports wireless speeds up to 867Mbps
· 5.8GHz Wi-Fi operation helps avoid congested 2.4GHz bandwidth
· Dual 14dBi antennas support stable directional wireless performance
· Bridge, Access Point, Router, and Repeater modes provide flexible deployment options
· Supports PoE power output for a single attached IP camera
· Includes 48V PoE injector for powering the CPE from up to 330ft away
Technical Context
The ANCP9005GQ is built around a Qualcomm Atheros chipset and operates on the 5.8GHz band for high-throughput wireless links. In bridge mode, the system LEDs provide signal strength and status feedback to help align the connection between endpoints.
Installation Notes
This CPE supports pole, wall, or rack mounting and is rated for outdoor operation down to -40°F. The included 48V PoE injector allows the unit to be powered over Ethernet from up to 330ft away, simplifying installation where local power is not available at the mounting point.
