AVYCON - AVC-NCB51M50-IK - 5MP H.265 LONG RANGE LPR BULLET NETWORK CAMERA
Product Overview
The AVYCON AVC-NCB51M50-IK is a 5MP H.265 long-range LPR bullet network camera designed for detailed vehicle and perimeter surveillance. It combines a motorized 5-50mm lens, Day & Night AUTO ICR, intelligent analytics, onboard storage, and rugged IP67/IK10/NEMA 4X protection.
Key Configuration
Model: AVC-NCB51M50-IK | Product Type: 5MP H.265 Long Range LPR Bullet Network Camera | Resolution: 2880x1620 @ 30fps | Lens: Motorized 5-50mm | Storage: microSD up to 512GB | Protection: IP67 / IK10 / NEMA 4X
Key Features
· 5MP video resolution up to 2880x1620 at 30fps
· H.265+, H.265, H.264+, H.264, and MJPEG encoding support
· Motorized 5-50mm lens for long-range license plate and detail capture
· Day & Night AUTO ICR for reliable imaging in changing light conditions
· 3D DNR, WDR, HLC, BLC, and ROI encoding for improved image performance
· Intelligent analytics for advanced event detection and monitoring
· Built-in microSD card slot for video and still image capture up to 512GB
· DC12V and PoE power supply support
Technical Context
The AVC-NCB51M50-IK is built for long-range surveillance applications where detailed target capture is required. Its 5-50mm motorized lens provides tighter framing for license plates, vehicles, entrances, and perimeter points, while WDR, HLC, BLC, 3D DNR, and ROI encoding help maintain usable video in challenging lighting scenes.
Installation Notes
The camera supports both DC12V and PoE power, giving installers flexibility during deployment. Its IP67, IK10, and NEMA 4X-rated housing makes it suitable for outdoor installations exposed to rain, dust, impact risk, and demanding environmental conditions, with remote monitoring available through AVYCON ONE and AVYCON CMSONE.
| Video | |
| Imaging Device | 1/2.7" Progressive CMOS |
| Resolution | Main Stream: 2880x1620, 2560x1440, 2304x1296, 1920x1080, 1280x720 Sub Stream: 1280x720, 640x480, 320x240 Mobile Stream: 640x480, 320x240 |
| Max. Framerate | Main Stream: Max. 30fps/25fps (60Hz/50Hz) Sub Stream: Max. 30fps (60Hz/50Hz) Mobile Stream: Max. 30fps (60Hz/50Hz) |
| Min. Illumination | Color: 0.002 lux @ F1.6 (AGC on) B/W: 0 lux (IR LED on) |
| Compression | Video: H.265+/H.265 Main Profile, H.264+/H.264 High Profile, MJPEG (Sub Stream Only) Audio: G.711a / G.711u |
| Bitrate Control | CBR or VBR (256Kbps ~ 8Mbps) |
| Lens | |
| Focal Length (Zoom Ratio) | 5–50 mm |
| Max. Aperture Ratio | F2.0±5% |
| Angular Field of View | Horizontal: 51°(W)~7°(T), Vertical: 27°(W)~4°(T), Diagonal: 60°(W)~8°(T) |
| Min. Object Distance | 0.65ft (0.2M) |
| Focus Control | Simple Focus |
| Lens Type | Motorized (Ø14) |
| Pan / Tilt / Rotate | |
| Pan / Tilt / Rotate Adjustment | Manual Adjustment |
| Operational | |
| Camera Title | Title Displayed up to 32 characters |
| Day & Night | AUTO (ICR) |
| Exposure Compensation | BLC, HLC, WDR |
| Digital Noise Reduction | 3D DNR |
| Digital Image Stabilization | N/A |
| Motion Detection | Rectangle Grid (8 Levels of Sensitivity) |
| Privacy Masking | 4 Rectangle Zones |
| Gain Control | AUTO |
| White Balance | AUTO / MANUAL |
| LDC | N/A |
| Eletronic Shutter Speed | AUTO / Manual (1/5 ~ 1/20000s) |
| Video Rotation | Flip / Mirror |
| Analytics | Face Detection (FD),Pedestrian & Vehicle Detection (PD&VD), Intrusion Detection (ID), Line Crossing Detection (TD), Tripwire Counting (TC), Stationary Object Detection (OBJ), Heat Map (HM), Crowd Density Detection (CD), Queue Length Detection (QD), License Plate Detection (LPR), Rare Sound Detection (RSD) |
| Alarm I/O | 1 Input / 1 Output |
| Alarm Triggers | Motion, Alarm, Sound Detection |
| Alarm Events | Notification via E-mail, Image file upload via FTP, Video file upload via FTP, Image file upload to Cloud (Dropbox), Video file upload to Cloud (Dropbox), Alarm Out, Micro SD recording at event triggered, Event Push via HTTP / UDP |
| Audio In | 1 Line-In (RCA), Built-in MIC |
| Audio Out | 1 Line-Out (RCA), Built-in Speaker |
| IR Viewable Length | 82ft(25M) |
| White Light LED | 262ft (80M) |
| Network | |
| Ethernet | RJ45 (10/100BASE-T) |
| Streaming | Unicast / Multicast |
| Protocol | TCP/IP, HTTP, DHCP, DNS, DDNS, RTP/RTSP, SMTP, NTP, UPnP, SNMP, HTTPS, FTP, RTMP (v8.2.3 firmware and above) |
| Security | Login Authentication, IP Address Filtering, User access log |
| Application Programming Interface | ONVIF Profile S/G/T, REST API |
| General | |
| Webpage Language | English, Korean |
| Edge Storage | Micro SD/SDHC/SDXC Slot (up to 512GB) with video and still image capture function |
| Memory | N/A |
| Environmental & Electrical | |
| Operating Temperature / Humidity | -31°~140°F (-35°~+60°C) / less than 95% RH |
| Storage Temperature / Humidity | |
| Certification | IP67 / IK10 / NEMA 4X / NDAA |
| Input Voltage | PoE (IEEE802.3at) / 12VDC |
| Power Consumption | DC12V: Max 8.7W / PoE(48V): Max 11.1W |
| Mechanical | |
| Color / Material | White / Metal |
| Product Dimensions / Weight | Ø5.29x13.86 in (Ø134.34x351.92mm) / 1.83lbs (829g) |
| DORI (EN62676-4-STANDARD) | |
| Detect (25PPM / 8PPF) | |
| Observe (63PPM / 19PPF) | |
| Recognize (125PPM / 38PPF) | |
| Identify (250PPM / 76PPF) | |
