AVYCON - AVC-NDE81M - 8MP Turret Network Camera Active Deterrence, Color

Product Overview

The AVYCON 8MP Motorized Varifocal Turret is a high-performance active deterrence camera that combines 4K clarity with a versatile 2.8-12mm motorized lens. It features a triple-light system (IR, warm light, and red/blue strobes) and a built-in siren to proactively deter intruders while providing full-color imaging in low-light conditions.

Key Configuration

• • Imaging device: 1/2.8" progressive CMOS • Effective pixels: 3,840 x 2,160 (8MP)
• • Lens: 2.8-12 mm motorised varifocal lens with an aperture of F1.2. Horizontal field of view: 107° (wide) to 34° (tele).
• • 2 IR LEDs: viewable length up to 98 ft (25 m) • 2 WarmLight LEDs: viewable length up to 82 ft (20 m)
  • 2 Red/Blue LEDs: 1 red + 1 blue
• • Triple streams: Main: up to 8MP@30fps; Sub: up to 720p@30fps; Mobile: up to VGA@30fps.
• • Power: DC 12 V or PoE (IEEE 802.3af). Power consumption: DC 12 V: max. 7.8 W; PoE: max. 9.1 W

Key Features

This 4K turret offers exceptional low-light performance with a 0.007 lux color rating and a versatile triple-illumination system. It serves as a proactive security hub, featuring Active Deterrence with red/blue strobes and a siren triggered by a deep library of AI analytics - including Face Detection, Heat Mapping, and Queue Length Detection. Two-way audio with custom voice support and high-speed H.265 compression ensures efficient, interactive monitoring.

Technical Context

Compliant with ONVIF Profiles S/G/T/M, this camera integrates seamlessly into diverse networks with support for RTMP streaming and IPv6. It prioritizes security via IP filtering and complex password authentication. For edge storage, the unit includes a 512GB Micro SD slot, while the hardware reset button and multi-browser support (Chrome, Edge, Safari) simplify long-term maintenance.

Installation Notes

Constructed from durable metal with an IP66 rating, the unit is built for extreme climates ranging from -35°C to 60°C. Its compact Ø126.5 × 108 mm frame is optimized for ceiling or wall mounting. By default, it utilizes warm light for full-color night video, but can be toggled to standard Infrared mode depending on the environment's specific stealth or lighting requirements.
