AVYCON - AVC-NDV51M - 5MP H.265 MOTORIZED VANDAL DOME NETWORK CAMERA Active Deterrence 24/7 Color
Product Overview
The AVYCON AVC-NDV51M is a 5MP H.265 motorized vandal dome network camera designed for 24/7 color surveillance with active deterrence. It combines a 2.8-12mm motorized lens, intelligent analytics, white light and strobe deterrence, built-in audio, and rugged IP67 protection for reliable indoor or outdoor security monitoring.
Key Configuration
Model: AVC-NDV51M | Product Type: 5MP Motorized Vandal Dome Network Camera | Resolution: 2880x1620 | Lens: 2.8-12mm Motorized Lens, F1.2 | Storage: MicroSD up to 512GB | Protection: IP67 | Power: DC12V / PoE
Key Features
· 5MP video resolution up to 2880x1620
· H.265+, H.264+, and MJPEG video compression support
· Full Color imaging with Active Deterrence functionality
· 2.8-12mm motorized lens for flexible viewing adjustment
· 3D DNR, WDR, HLC, BLC, and ROI encoding for improved image quality
· Intelligent Analytics for smarter event monitoring
· White Light LED and blue/red strobe light deterrence
· Built-in microphone and speaker for two-way audio
· Built-in microSD card slot supporting up to 512GB
· Remote monitoring through AVYCON ONE and AVYCON CMSONE
Technical Context
The AVC-NDV51M uses efficient H.265+ compression to reduce storage and bandwidth requirements while maintaining detailed 5MP video. Its image enhancement tools, including WDR, HLC, BLC, 3D DNR, and ROI encoding, help maintain usable video quality in scenes with mixed lighting, glare, shadows, or high contrast.
The active deterrence system combines white light illumination with blue and red strobe alerts, while the built-in microphone and speaker allow audio interaction from the camera location. Intelligent analytics support more targeted event detection and help improve response accuracy compared with basic motion-based monitoring.
Installation Notes
The IP67-rated enclosure supports outdoor installation where protection from rain and dust is required. DC12V and PoE power options provide flexible deployment, while the motorized 2.8-12mm lens allows installers to adjust the field of view after mounting.
| Video | |
| Imaging Device | 1/2.7" |
| Effective Pixels | 5MP 2880(H)x1620(V) |
| Scanning System | Progressive CMOS |
| Min. Illumination | Color 0.002lux @ F1.0(AGC ON); B/W 0 lux @ IR ON |
| Lens Type | |
| Focal Length (Zoom Ratio) | 2.8-12mm |
| Max. Aperture Ratio | F No. 1.2 |
| Angular Field of View | H: 113(W)-35(T)°, V: 59(W)-20(T)°, D: 138(W)-41(T)° |
| Min. Object Distance | 1.5m |
| Lens Type | Ø16.7 |
| Operational | |
| IR LED | 2 |
| WarmLight | 2 |
| Red Blue Light | 2 (1 Red & 1 Blue) |
| IR Viewable Length | Up to 82ft (25m) |
| WarmLight Viewable Length | Up to 65ft (20m) |
| Type of Complementary Light | Default warm light, Switchable infrared light |
| Motion Detection | Off/On (8 Level) |
| Wide Dynamic Range | WDR |
| Digital Noise Reduction | 3D DNR |
| Image Setting | Full Color Mode / Day & Night Mode / Smart Illumination |
| White Balance | Auto/Manual |
| Electronic Shutter Speed | 1/5 ~ 1/20000s |
| On-Board Storage | Micro SD slot, up to 512GB |
| Alarm | 1 input, 1 output |
| Alarm Event | Warning Light, Siren, E-mail Notification, Event Push, FTP Picture Upload, Micro SD recording |
| Audio | 1 input, 1 output, Built-in microphone & Speaker |
| Custom Voice | Yes |
| Hardware Reset | Yes |
| Analytics | Face Detection (FD), Pedestrian & Vehicle Detection (PD&VD), Intrusion Detection (ID), Line Crossing Detection (TD), Tripwire Counting (TC), Stationary Object Detection (OBJ), Heat Map (HM), Crowd Density Detection (CD), Queue Length Detection (QD), License Plate Detection (LPR), Rare Sound Detection (RSD), Tripwire Count (TC), Queue Length Detection (QD), Heat Map (HM), Loitering Detection (LD), Region Entrance / Exiting Detection |
| Network | |
| Ethernet | RJ45(10/100BASE-T) |
| Video Compression Format | H.265/H.264 |
| Resolution | Main Stream@30fps 5MP(2880x1620), 4MP(2560x1440), 3MP(2304x1296), 1080P(1920x1080), 720P(1280x720) Sub Stream@30fps 720P(1280x720), VGA(640x480), QVGA(320x240) Mobile Stream@30fps VGA(640x480), QVGA(320x240) |
| Video Quality Adjustment | 256Kbps ~ 8Mbps |
| Bitrate Control Method | CBR/VBR |
| IP | IPv6 |
| Protocol | TCP/IP, HTTP, DHCP, DNS, DDNS, RTP/RTSP, SMTP, NTP, UPnP, SNMP, HTTPS, FTP, RTMP (v8.2.3 firmware and above) |
| Security | IP address filter; Complicated password; Authenticated username and password |
| Application Programming Interface | ONVIF (Profile S / G / T / M) |
| Web Viewer | IE10/11, Safari V12.1 above, Firefox V.52 above, Google chrome V.57 above, Edge V.79 above |
| Environmental | |
| Operating Conditions | -31～+140°F(-35～+60°C) / less than ≤ 90% RH |
| Ingress Protection | IP67 |
| Electrical | |
| Input Voltage / Current | D12V/POE(IEEE802.3af) |
| Power Consumption | DC12V: max 5.7W; POE (48V): max 7.3W |
| Mechanical | |
| Material | Metal |
