AVYCON - AVC-TE51M-B - 5 Megapixel HD-TVI/CVI/AHD/Analog Dome Camera with 2.7-13.5mm Lens, Black

Product Overview

The Avycon AVC-TE51M-B is a 5MP 4-in-1 eyeball camera designed for flexible HD analog surveillance installations. It supports HD-TVI, CVI, AHD, and CVBS analog video formats, with a motorized 2.7-13.5mm varifocal lens, true day/night ICR, Smart IR illumination, and an IP67-rated outdoor housing.

Key Configuration

Model: AVC-TE51M-B | Product Type: 5MP Eyeball Camera | Resolution: 5MP / 2592 x 1944 | Lens: Motorized Varifocal 2.7-13.5mm | Video Format: HD-TVI / CVI / AHD / CVBS Analog | IR Range: Up to 115ft | Protection: IP67 | Power: DC12V

Key Features

 · 5MP resolution delivers detailed 2592 x 1944 surveillance video

 · Supports HD-TVI, CVI, AHD, and CVBS analog video formats

 · Motorized 2.7-13.5mm varifocal lens allows flexible scene adjustment

 · True Day & Night ICR supports clear imaging in changing light conditions

 · Smart IR illumination provides night visibility up to 115ft

 · DIP switch format selection simplifies camera output configuration

 · 2D DNR, 3D DNR, WDR, and BLC improve image quality in difficult lighting

 · IP67 ingress protection supports outdoor installation

Technical Context

The AVC-TE51M-B is designed for hybrid analog HD systems that require compatibility across multiple recorder standards. Its 4-in-1 output and DIP switch format selection allow installers to match the camera to HD-TVI, CVI, AHD, or CVBS infrastructure while maintaining high-resolution 5MP video.

Installation Notes

The motorized varifocal lens allows the viewing angle to be adjusted after installation for more precise coverage. Its IP67-rated housing supports outdoor use, while Smart IR illumination and true day/night ICR help maintain usable video in low-light and nighttime environments.
