AVYCON - AVN-W10-2P08W96G - 8 Ports Unmanaged Gigabit Outdoor Weatherproof PoE Switch with 2 SFP Uplink ports, 96W PoE Budget
Part number:
AVN-W10-2P08W96G
Price:
8 Ports Unmanaged Gigabit Outdoor Weatherproof PoE Switch with 2 SFP Uplink ports, 96W PoE Budget.
Features:
- IEEE802.3, IEEE 802.3u, IEEE802.3ab, IEEE802.3z, IEEE802.3af, IEEE802.3at
- 8 x 10/100/1000 Base-TX PoE Ports + 2 SFP (1G)
- 100-240VAC Input
- High back-plane bandwidth 4.8Gbps
| ATTRIBUTE | |
| Networking Interfaces | 8 x 10/100/1000 Mbps RJ45 Ethernet Ports 2 x 1Gbps SFP SLots |
| LED Indicators | Power, Link/Act, PoE |
| PERFORMANCE | |
| Switching Capacity | 20Gbps |
| Forwarding Capacity | 14.88 Mpps |
| Forwarding Mode | Store and Forward |
| Packet Buffer Memory | 2 Mbit |
| MAC Address Table | 4K |
| PoE Budget | 96W |
| PHYSICAL | |
| Dimension | 295mm x 206mm x 50 mm |
| Weight | 4lbs (1.8kg) |
| Operating Temperature | -20 to 60°C |
| Storage Temperature | -20 to 70°C |
| Operating Humidity | 5 to 95% Noncondensing |
| Power Method | 100-240VAC 50/60Hz |
| Max. Power Consumption | Including PoE Output: 96W Excluding PoE Output: 10W |
| EMC Safety | FCC, CE, RoHS |
| POWER OVER ETHERNET | |
| PoE Interfaces | Ports 1-8 |
| PoE Standard | IEEE802.3af, IEEE802.3at |
| Max. PoE Wattage per Port | 30W |
| PoE Voltage | 48VDC |
| PoE Pin Assignment | V- (RJ45 Pin1,2), V+ (RJ45 Pin 3,6) |
| PACKAGE LIST | |
| PoE Switch | 1each |
| User Manual | 1each |
| Power Adapter | 1each |
Name
Description
Size
Downloads
File
Datasheet
1.4mb
