Hanwha - SBO-100B1 - Backbox for Bullet Cameras

Part number:
SBO-100B1
Price:

The Hanwha SBO-100B1 is a durable, aluminum junction back box engineered specifically for flat-surface installation of Hanwha's small-to-mid format bullet cameras. It serves as a dedicated, weather-sealed enclosure behind the camera's base bracket to cleanly house the physical pigtail and network connections.

Compatible with the following: QNO-6012R, QNO-6022R, QNO-6032R, QNO-6082R, QNO-8010R, QNO-8020R, QNO-8030R, QNO-6010R, QNO-6020R, QNO-6030R, QNO-6070R, QNO-7010R, QNO-7020R, QNO-7030R, QNO-7080R, HCO-7010R, HCO-7020R, HCO-7030R, HCO-7070R, HCO-6070R, HCO-6080R, SNO-L6083R, SNO-L5083R, SCO-6083R.

MaterialsAluminum
ColorDark gray
Applicable Model

QNO- 7080R/6070R/7010R/7020R/7030R/
6010R/6020R/6030R/8010R//8020R/8030R
6012R/6022R/6032R/6082R/SNO-L6083R/L5083R/
SCO-6083R/HCO-7070R/6080R/6070R/7010R/7020R/7030R

Compatible with single, double, &
4" octagon gangboxes.

Dimensions (WxHxD)Ø125.6 x 45.0mm (Ø4.95" x 1.77")
Weight320g (0.71 lb)
Name
Description
Size
Downloads
File
CAD
0.2mb
File
Manual
1.7mb
File
Datasheet
2mb
File
Compliant Product List
0.5mb
