Bolide - BTG-N1509IROD/2.8 - 5MP IP 2.8mm Fixed Lens Turret Camera
Part number:
BTG-N1509IROD/2.8
Price:
5MP IP 2.8mm Fixed Lens Turret Camera, with Built-in Mic, IR Up to 65Ft, POE, 12VDC, Dark Gray
Features:
- Using High-performance processor 5.0 mega pixel CMOS imaging sensor
- Supports 5MP (2592*1944) 15fps monitoring
- Using Linux embedded OS, low power consumption, steady and credible
- Using H.265, H.264 encoding, high compression ratio and lower stream
- Supports ICR automatic switchover, achieve round-the-clock monitoring
- Supports network interrupt, IP conflict, motion detection, video blind smart alarm
- Supports abnormal automatic recovery and network interrupt auto-reconnect functionality
- Supports watermark encryption, prevent data from being tampered
- Support DC12V/POE, easy to install
- Supports IP66 waterproofing grade
- Supports anti-static and surge
- Supports ONVIF protocol access
- Infrared distance of 20 meters
- Provide SDK development kit, access to other video management platform
| Image sensor | 1/2.7” CMOS |
| Max resolution | 2592*1944 |
| Electronic shutter | Manual / automatic adjustment, 1/25 sec to 1/10000 sec |
| Minimum illumination | 0. 1Lux@F1.2(color mode); 0.01Lux@F1.2(black and white mode) |
| Day & Night | Color/black and white/automatic, IR-CUT auto |
| Scanning method | Progressive scan |
| WDR | Not support |
| SNR | >50dB |
| Gain Control | Automatic |
| White Balance | Automatic |
| BLC | Support |
| Infrared distance | 20m |
| Focal length | 2.8mm |
| Type | Fixed focal lens |
| Iris control | Fixed iris |
| Interface | M12 |
| Video compression standard | H.265+/H.265/H.264 |
| Video bit rate | 8kbps~32Mbps, Customizable |
| Video frame rate | Main Stream (2592*1944@15fps), secondary stream (D1@25fps) |
| Image settings | Brightness / contrast / sharpness / saturation |
| OSD superimposing | Time / channel name / position / picture |
| Recording mode | Manual recording, time recording, recording descending order of priority: manual / timing |
| User management | Support multi-levels user administration |
| Restore the default | Support for a key to restore the default |
| Browser | Support IE6 and above |
| Alarm and data transmission | Support FTP, E-mail Browser, CMS |
| Privacy masking | Support |
| Motion detection | Support |
| Network interface | 1 RJ45 10/100M Ethernet interface |
| Network protocol | TCP/IP/HTTP/RTSP/FTP/PPPOE/RTCP /SMTP/DHCP/DDNS/NTP/UPnP/SNMP |
| Access standard | ONVIF |
| Smartphone platform | Support iPhone, iPad, Android |
| Power supply | DC12V/POE |
| Power consumption | 10W Max |
| Working temperature | -20°C ~ 55°C |
| Working humidity | ≤95% |
| Protection class | IP66 |
| Shell Material | Metal |
| Mounting | Wall/ceiling |
