BOLIDE - SVR9532H/NDAA - 32-Channel Hybrid H.264 5MP Lite DVR HD Over Coax

Product Overview

The Bolide SVR9532H/NDAA is a versatile, government-compliant 32-channel Hybrid DVR designed to bridge the gap between legacy analog systems and modern IP surveillance. It supports AHD, TVI, CVI, and CVBS formats, plus up to 4 dedicated IP channels, allowing for a maximum of 40 total inputs. With its 4K HDMI output and expansive 24TB storage capacity, it provides a high-resolution command center for large-scale retrofits.

Key Configuration

• • Analog video input: 32 channels; IP video input: up to 4 channels (total hybrid: up to 40 channels)
• • IP recording bandwidth: 32 Mbps; max output bandwidth: 128 Mbps
• • HDD interface: 2 × SATA, up to 24TB total (12TB per bay)
• • Video outputs: HDMI (up to 4K/3840×2160) and VGA
• • Audio: 4 inputs / 1 output (RCA); alarm: 8 inputs / 1 output

Key Features

The SVR9532H/NDAA is a high-density hybrid powerhouse capable of managing up to 32 analog channels and 4 IP channels simultaneously. It supports 16-channel synchronous playback and provides real-time decoding for up to 16 channels at 5MP. Security operators can utilize diverse recording modes - Continuous, Manual, or Motion Detect - and take full control of PTZ cameras via RS-485 or Control over Coax (CoC).

Technical Context

Running on a stable embedded Linux OS, this DVR supports H.264 compression and is selectable between NTSC and PAL systems. The video output is highly adaptable, supporting resolutions from standard HD up to 4K (3840×2160) via HDMI. The hardware includes dual USB ports for peripheral control and data backup, while the network interface leverages P2P technology for instant mobile access on iOS and Android devices.

Installation Notes

Designed for professional rack or shelf placement, the unit measures 378 × 326 × 66 mm and operates on a DC12V/5A power supply. It is built to perform in varied environments with an operating temperature range of -10°C to 55°C. As an NDAA-compliant device, it is a secure choice for updating existing analog infrastructure in government or high-security commercial applications without requiring a full cable overhaul.
