Computar - EL3Z0416SCS-MPWIR - LensConnect 5 Megapixel 1/1.8" 4-10mm Lens F1.6 I2C Interface (CS-Mount)

Product Overview

The Computar EL3Z0416SCS-MPWIR is a motorized varifocal LensConnect lens designed for 5-megapixel security and machine vision applications. Its 4-10mm focal length, IR-corrected optics, and compact embedded-control design support precise imaging in day and night surveillance systems.

Key Configuration

LensConnect series lens; 5MP resolution support; 4-10mm varifocal range; motorized zoom and focus; I2C interface; IR-corrected optics; P-Iris control; floating focus design; minimum object distance 0.2m.

Key Features

• Motorized zoom and focus enable remote field-of-view and focal-plane adjustment
• I2C interface supports direct board-level control from embedded camera systems
• IR-corrected optical design helps maintain focus during day/night operation
• P-Iris control supports optimized aperture management for contrast and depth of field
• Floating focus mechanism maintains 5MP image performance across the zoom range

Technical Context

The SCS variant uses an I2C control interface for embedded integrations, allowing a camera SoC or external controller to command lens functions through SDA and SCL communication lines. The lens is designed to maintain sharp imaging from 0.2m to infinity.

Installation Notes

This lens is intended for compatible embedded vision, IP camera, and surveillance platforms that can support motorized lens control through I2C communication and P-Iris operation.
