Computar - ML3Z1226SC-MPW - 9 Megapixel 2/3" 12-36mm Lens F2.6 P-Iris I2C Interface (C-Mount)

Product Overview

The Computar ML3Z1226SC-MPW is a 9-megapixel motorized varifocal lens from the LensConnect series, designed for machine vision, factory automation, and embedded imaging systems. It supports 2/3" sensors and provides a 12-36mm focal range for remote field-of-view adjustment.

Key Configuration

9MP lens; LensConnect series; 2/3" sensor format; 12-36mm motorized varifocal range; 3x optical zoom; I2C interface; board-level control; motorized zoom; motorized focus; motorized iris; P-Iris; optional internal IR-cut filter switcher.

Key Features

• I2C embedded control allows direct zoom, focus, and iris commands from a camera SoC or microcontroller
• 12-36mm focal range supports remote adjustment across a 3x optical zoom range
• Stepper-driven zoom and focus provide repeatable preset positioning for automated workflows
• P-Iris control helps maintain the aperture needed for depth of field, contrast, and image sharpness
• Floating focus design helps preserve 9MP image quality across the zoom range and image field

Technical Context

The SC version uses a 4-wire I2C control interface with SDA, SCL, GND, and 5V connections, making it suitable for direct board-level integration without USB cabling. The lens is specified with a 0.1m minimum object distance and can support an internal IR-cut filter switcher option for day/night imaging designs.

Installation Notes

This lens is intended for embedded camera platforms and automated inspection systems that require motorized optical control from the host hardware. Its 2/3" sensor coverage and remote lens functions make it suitable for installations where manual lens adjustment is impractical.
