Computar - VL1226U-MPZ - 20MP, 1”, 12mm, F2.6, LensConnect, P-Iris with Remote Adjustment, (C-mount)
Part number:
VL1226U-MPZ
Price:

LensConnect Series of motorized lenses are engineered to enable power supply and control through USB.  This innovative Plug and Play lens series allows remote adjustment of the zoom*, focus, or iris and comes with a simple set-up software compatible with Windows or Linux (*zoom adjustment for varifocal models only).



The remote control is easy to achieve - even without any prior knowledge of the lens. The floating focus design delivers ultra-high resolution from near to far, and stepper motors enable precise focus control and high repeatability.



Features:

  • 20MP
  • Suitable for large format sensors (IMX183)
  • 1” format
  • 12mm, f2.6
  • P-Iris  with remote adjustment
  • Power supply & control through USB
  • Floating focus design achieves ultra-high resolution from near to far.
  • Stepper motors realize precise focus control and high repeatability
  • Easy-to-install by free control software
Optical Specifications
 Model No. VL1226U-MPZ Effective Lens Aperture

 Front:φ22.6mm   Rear:φ15.1mm

 Focal Length 12mm Back Focal Length 10.6mm (In Air)
 Operation Range Iris F2.6 - F16.0 Flange Back Length 17.526mm (In Air)
 Focus 0.1m - Inf. Max. Image Format 12.8mm x 9.6mm(φ16mm)
 Object Dimension  at M.O.D. 1      Type 123.2mm x 91.9mmDistortion 1      Type 0.0%
 2/3   Type   84.1mm x 62.7mm 2/3   Type -1.1%
1/1.8 Type   68.5mm x 51.2mm1/1.8 Type -1.0%
 Angle of View D 1 Type 67.4° 2/3 Type 49.8° 1/1.8 Type 41.5°
 H 56.7° 40.7° 33.7°
 V 44.1° 31.0° 25.5°
Mechanical & Electrical Specifications
 Control Interface USB2.0 Dimensions As per the attached drawing
 Power mode Bus powerd (500mA) Mount C-Mount
 Connector USB TypeA Weight 273g
 Operating Temperature -10℃ - +50℃ Tripod Screw -
 Control Iris Motorized Filter thread M46 x P0.75mm
 Focus Motorized
