Cyber Power - BP240V30ART3UTAA - UPS SYSTEMS TAA Compliant External Battery Module for OL6000RT3UTFTAA
Part number:
BP240V30ART3UTAA
Price:

The CyberPower BP240V30ART3UTAA rack/tower convertible Extended Battery Module (EBM), which extends battery runtimes during power outages, is designed for Smart App Online UPS systems OL6000RT3U, OL6000RT3UTF, OL6000RT3UPDU, OL6000RT3UPDUTF, OL6KRT3UHW, OL8000RT3U, OL8000RT3UTF, OL8000RT3UPDU, OL8000RT3UPDUTF, OL8KRT3UHW, and OL10000RT3U, OL10000RT3UTF, OL10000RT3UPDU, OL10000RT3UPDUTF, and OL10KRT3UHW. This EBM takes 3U of rack space and can be installed in a rack or tower configuration to match the UPS form factor. It also has a built-in battery charger, providing Fast Charge Technology to quickly restore the backup power supply to full capacity.



Up to ten EBMs can be added to the UPS, and the module's DC plug-and-play power connectors allow for daisy-chaining EBMs to a UPS system. The BP240V30ART3UTAA typically has a UPS charging time of four hours regardless of whether one or ten EBMS are installed. It comes with a three-year warranty.



Features:

  • Extended Battery Module
    Expands runtime and quickly restores full backup power with Fast Charge Technology.
  • Hot-Swappable Batteries
    Can be replaced without powering down vital equipment.
  • Fast Charge Technology
    Uses a built-in battery charger in each EBM for quick charging, regardless of the number of EBMs attached to a UPS.
  • Smart Battery Management
    Uses a three-cycle charging mode that improves battery life and reduces generated heat.
  • Plug-and-Play DC Connectors
    Allow for daisy-chaining additional EBMs to a UPS system.
  • User-Replaceable DC Fuses
    Are located behind an easy-access panel.
  • Resettable AC Circuit Breaker
    Resets the UPS swiftly in case of an overload.
  • Rack/Tower Configuration
    Allows for horizontal rack or vertical tower installation.
  • Three-Year Warranty
    Covers defects in materials and workmanship in the product under normal use and conditions within three years of the purchase date. See warranty for details.
GENERAL
Voltage240V
Amperage30A
BATTERY
Battery TypeSealed Lead-Acid
Battery Size12V/7.2AH
Hot-SwappableYes
Replacement BatteryRB1272X20
Battery Quantity20
User ReplaceableYes
Typical Recharge Time4 Hours
Built-in ChargerYes
Expansion Ready (Daisy-Chain)Yes - Power plugs for Module and Charger
PHYSICAL
Rack Size3U
Mounting HardwareIncluded
Enclosure ConstructionSteel
Dimensions (WxHxD) (in.)17.05 x 5.2 x 26
Dimensions (WxHxD) (mm.)433 x 132 x 660
Weight (lbs.)167.2
Weight (kg.)76
Shipping Dimensions (WxHxD) (in.)23.62 x 14.76 x 35.43
Shipping Dimensions (WxHxD) (mm.)600 x 375 x 900
Shipping Weight (lbs.)204.6
Shipping Weight (kg.)92.8
ENVIRONMENTAL
Operating Temperature32°F to 104°F / 0°C to 40°C
Operating Relative Humidity0% - 90% non-condensing
Operating Elevation0-10000 feet (0-3000 meters)
Storage Temperature5°F to 113°F / -15°C to 45°C
Storage Relative Humidity0% - 95% non-condensing
Storage Elevation0-50000 feet (0-15000 meters)
CERTIFICATIONS
SafetyUL1778, CSA C22.2 NO.107.3-05,
FCC DOC Class A
EnvironmentalRoHS Compliant
WARRANTY
Product Warranty3 Years Limited



Name
Description
Size
Downloads
File
Data Sheet
0.8mb
File
User Manual
1.4mb
