Cyber Power - OL6KRT2UTFHWIORTAA - UPS SYSTEMS TAA Compliant UPS, 6000VA/6000W TAA 208V to 120V Step-down Transformer
Part number:
OL6KRT2UTFHWIORTAA
Price:

The CyberPower Smart App Online OL6KRT2UTFHWIORTAA rack/tower step-down isolation transformer converts 208VAC input voltage from utility power, UPS’s, and generators to 120VAC output. The OL6KRT2UTFHWIORTAA has a capacity of 6,000 VA / 6,000 Watts. It features six (6) NEMA 5-20R outlets that can support output to NEMA 5-15P and 5-20P plug power cords, and over temperature protection to safeguard against heat damage.

The OL6KRT2UTFHWIORTAA complies with the U.S. Trade Agreement Act (TAA), and comes with a three-year warranty.



Features:



  • Step-Down Transformer
    The step-down transformer provides IT managers the ability to support both 120VAC and 208VAC output requirements with a single UPS solution. With six (6) NEMA 5-20R outlets available, users will have sufficient outlets to connect multiple 120V devices running at 15A and/or 20A. If additional outlets are needed, CyberPower manufactures a number of different Power Distribution Units (PDU) making it easy to address your specific outlet needs.
  • NEMA L6-30P Plug
    A 6-foot, 3-wire power cord with a NEMA L6-30P plug to ROJ (removed outer jacket) is included.
  • Frequency Supported
    The OL6KRT2UTFHWIORTAA has the flexibility to support both 50Hz and 60Hz output.
  • Over Temperature Protection
    Protects the OL6KRT2UTFHWIORTAA from damage if the internal heat exceeds safe operating parameters.
  • Resettable Input and Output Circuit Breakers
    Convenient, resettable switches that provide protection from an input or output overload and faults.
  • Three-Year Warranty
    CyberPower will repair or replace a defective product within three years of the purchase date. See warranty for details.
  • Technical Support
    CyberPower will assist customers with any product, installation, or warranty concerns.
  • ISO and Safety Certifications
    CyberPower manufacturing facilities are state-of-the-art and ISO-9001 Quality Tested. Our products are certified by the CE, UL, and cUL.
General
Model TypeStep-Down Transformer
Over Temperature ProtectionYes
Input
Nominal Input Voltage200, 208, 220, 230, 240VAC
Input Voltage Range200-240VAC
Input Frequency Range50/60Hz
Input Current Rating30A
Plug StyleHardwire Terminal (NEMA L6-30P power cord included)
Cord Length6 ft
Output
VA6000 (6.0 kVA)
Watts6000 (6.0 kW)
Nominal Output Voltage100, 110, 115, 120VAC / 200, 208, 220, 230, 240VAC
Frequency50/60Hz
Outlets – Total6
Outlet TypeHardwire Terminal, (6) NEMA 5-20R
Overload ProtectionOutput Circuit Breakers
Physical
Form FactorRack / Tower Convertible
Enclosure ContructionSteel
Mounting Hardware IncludedYes
Step-down Tranformer
Dimensions (WxHxD) (in.)17 x 3.5 x 24
Dimensions (WxHxD) (mm.)433 x 88.9 x 600
Weight (lbs)95.5
Weight (Kg)43.4
Installed Rack Height2U
Step-down Tranformer(Shipping Dimensions)
Dimensions (WxHxD) (in.)23.6 x 13 x 35.4
Dimensions (WxHxD) (mm.)600 x 330 x 900
Weight (lbs)128.2
Weight (Kg)58
Environmental
Operating Temperature32 °F to 104°F / 0°C to 40 °C
Operating Humidity0% – 90% non condensing
Operating Elevation0-10000 feet (0-3000 meters)
Storage Temperature-4°F to 113 °F (-20°C to 45 °C)
Storage Relative Humidity0% – 95% non condensing
Storage Elevation0-50000 feet (0-15000 meters)
Certifications
SafteyUL, cUL, CE
ROHSROHS Compliant
Warranty
Product Warranty3 Years Limited
Ext. 2-Year WarrantyWEXT5YR-ACC2C
