Digital Watchdog - DW-BJAi2R64T - Blackjack Rack NVR Server (Powered by DW Spectrum IPVMS), 8 DW Spectrum recording licenses and 8 IVA Ai Server licenses pre-installed, 128 cameras @ 2.1MP, 128 analytic streams, Hosting Intelligent Video Analytics Ai
Part number:
DW-BJAi2R64T
Price:

Blackjack Rack NVR Server (Powered by DW Spectrum IPVMS), 8 DW Spectrum recording licenses and 8 IVA Ai Server licenses pre-installed, 128 cameras @ 2.1MP, 128 analytic streams, Hosting Intelligent Video Analytics Ai software deep learning and color filter, Server-side analytics for non-analytic cameras, Deep learning classifiers, 600 Mbps of recording throughput, Windows 10 Pro on mirrored SSD's, 2000W Dual Power Supply, 2U rack-mount, 48TB usable Raid storage Raid 5, Dual Intel Xeon Gold Processor, 64GB of memory, 2x 10GB SFP+Fiber, 2x 1G Ethernet,  Graphic System Health Monitor, True Enterprise Scalability, Automatic Camera Detection, Local Client Display, Fully, Customizable Layouts, Easy Drag and Drop Camera Management and Recording, E-Mapping, Advanced Motion Masking and Sensitivity Settings,  Keyboard, Mouse and Rail kit  are  included,  NDAA, TAA, 5 Year Onsite Next Business Day Keep Your Hard Drive Warranty.



Blackjack Ai Rack Artificial Intelligence Network Video Recorders (AI NVR) are purpose-built servers, with built-in server-side analytics that unlock advanced AI capabilities on any connected video stream. These cost effective, plug-and-play appliances combine high-performance recording with video analytics in an easy-to-deploy turnkey solution. The NDAA/TAA compliant, UL listed servers feature up to 320Mbps throughput, dual Intel Xeon processors and come preloaded with DW Spectrum IPVMS and eight complimentary recording licenses. Add the power of advanced neural network-based analytics to your video streams with a Blackjack Ai NVR. The servers come complete with a 5 year, on-site, Next Business Day*, Keep Your Hard Drive warranty to ensure peace of mind.



Features:

  • Hosting Intelligent Video Analytics Ai software deep learning and color filter
  • Server-side analytics for non-analytic cameras
  • Deep Learning classifiers
  • A single device for NVR and Analytics server for lower deployment cost
  • Record and manage single- and multi-sensor IP cameras of any resolution up to 320Mbps throughput
  • Up to 128 analytic streams
  • 64-160TB raw internal storage with RAID options
  • Hot Swappable HDDs
  • OS RAID 1, data RAID5 with dedicated RAID controller
  • Redundant power supply
  • Dedicated GPU for client application for easy configuration
  • Dual Intel Xeon processor
  • 2x 10Gb SFP+, 2x 1Gb base-T network ports
  • Windows 10 on separate SSD
  • Hosting DW Spectrum for setup, configuration, monitoring and recording
  • One-time recording license charge, fully transferable between cameras and encoders
  • Two (2) 4-channel licenses included for a total of 8 recording channels (DW-SPECTRUMLSC004)
  • Two (2) 4-channel Ai license included (DW-DWAiSLSC004)
  • No annual maintenance fees
  • Rail kit included
  • USB mouse and keyboard included
  • Designed, assembled and tested in the U.S.A.
  • Keep your failed drive warranty and retain your data
  • UL Listed
  • NDAA/TAA compliant
  • 5 year warranty, next business day on-site hardware service*, keep your hard drive - *after remote diagnosis
Specifications
VIDEO
CPU2x XEON Gold 6248R
Display ModesUnlimited, Customizable, Sequence
Local Video OutputsFor initial system configuration, 1 DisplayPort, 1 display output at a time
Memory64GB
Video CardNVIDIA RTX A4000 16GB
Video CompressionH.264, H.265
Video Operating SystemWindows® 10 IoT Enterprise LTSC
OS on SSD2 x 240GB NVMe SSD (RAID1)
Max throughput (Mbps)320Mbps
STORAGE
Raw internal storage options64TB, 96TB, 128TB, 160TB
RAID OptionsOS RAID1, RAID5
Max HDD Bay8 x SATA HDD
Maximum Storage160TB RAID 5 (140TB usable storge) (DW-BJAI2R160T), 128TB (112TB usable storage) (DW-BJAI2R128T), 64TB (48TB usable storage) (DW-BJAI2R64T), 96TB (80TB usable storage) (DW-BJAI2R96T), 160TB
PERFORMANCE
Max # of analytic streams (secondary)Up to 128
Performance featuresA single device for NVR and Analytics server for lower deployment cost, AVI file backup, Camera Color Control, Deep learning classifiers and logical rules engine, Import and export settings, Server-side analytics for non-analytic cameras, Watermak exported video
Playback FunctionsCalendar, Event search, Smart motion search, Thumbnail search, Timeline
PTZ controlONVIF
Recording ModesContinuous, Motion + low res always, Motion + Object, Motion + Object + Low res, Motion detection, Object + Low res, Object only
System OperationGraphical user interface (GUI), Remote via DW Spectrum IPVMS, USB mouse (included)
NETWORK
BackupNetwork backup via DW Spectrum IPVMS
Ethernet Ports2x 10GB SFP+ Fiber, 2x 1G Ethernet (RJ45), iDRAC9 Enterprise
Pre-loaded VMS softwareDW Spectrum® IPVMS
Network Remote SoftwareCross-platform - Windows®, Linux Ubuntu® and Mac®, DW Mobile Plus, DW Spectrum Mobile App
ELECTRICAL
Power Consumption2000W dual power, A UPS is recommended, Redundant power supply
GENERAL
AccessoriesKeyboard, Mouse
Ai Configuration Tool supported OSCross-platform - Windows® and Linux Ubuntu®
General Dimensions17.08" x 29.03" x 3.4" (434 x 737.5 x 86.8mm)
Included DW Ai Server Licenses8 (2x DW-DWAiSLSC004)
Operating Temperature and Humidity41 ~ 104 °F (5~40 °C), 5~85% RH
Preloaded Analytic softwareDW Ai Server
Rail kitIncluded
Recording Licenses (Optional. Sold Separately)Custom-ordered licenses are available by request.
DW-SPCP04LSC004 - Four (4) DW Spectrum® Analog Encoder IPVMS Licenses
DW-SPCP16LSC016 - Sixteen (16) DW Spectrum® Analog Encoder IPVMS Licenses
DW-SPECTRUMLSC001 - Single DW Spectrum® IPVMS Recording License
DW-SPECTRUMLSC004 - Four (4) DW Spectrum® IPVMS Recording Licenses
DW-SPECTRUMLSC010 - Ten (10) DW Spectrum® IPVMS Recording Licenses
DW-SPECTRUMLSC020 - Twenty (20) DW Spectrum® IPVMS Recording Licenses
DW-SPECTRUMLSC050 - Fifty (50) DW Spectrum® IPVMS Recording Licenses
DW-SPECTRUMLSC100 - One hundred (100) DW Spectrum® IPVMS Recording Licenses
DW-SPIOLSC001 - Single DW Spectrum® I/O Module IPVMS License
DW-SPVWALL1X2 - Single DW Spectrum® Video Wall IPVMS License
Lifetime upgrades are included with no annual renewal fees.
USB interfaceYes
Warrantykeep your hard drive, Next business day on-site hardware service (after remote diagnosis)
Weight (barebone, HDD not included)88.2 lbs (40 kg)
Form FactorRack mount
