Blackjack AI mid-tower, Windows OS on SSD, 4 DW Spectrum recording licenses and 4 IVA Ai Server licenses pre-installed, 64 cameras @ 2.1MP, 64 analytic streams, 480Mbps throughput, Intel i7, 32GB RAM, 48TB storage, 5 Year Limited Warranty
Blackjack Ai Tower Artificial Intelligence Network Video Recorder (Ai NVR) is a purpose-built server, with built-in server-side analytics that unlock advanced Ai capabilities on any connected video stream via our DW Ai Server software. This cost-effective, plug-and-play appliance combines high-performance recording with video analytics in an easy-todeploy turnkey solution. The NDAA and TAA compliant server features up to 320Mbps throughput, 64 secondary streams and comes preloaded with DW Spectrum IPVMS, with four complimentary recording licenses. Add the power of advanced neural-network-based analytics to your video streams with a Blackjack Ai NVR, backed by our 5 year limited warranty.
Features:
VIDEO | |
---|---|
CPU | Intel Core i7 processor |
Display Modes | Unlimited, Customizable, Sequence |
Local Video Outputs | 1x mini Display Port, For initial configuration and server management |
Memory | 32GB |
Video Card | NVIDIA RTX A2000 12GB |
Video Compression | H.264, H.265 |
Video Operating System | Windows 10 IoT Enterprise LTSC |
OS on SSD | 480GB SSD |
Max throughput (Mbps) | 320Mbps |
STORAGE | |
Raw internal storage options | ![]() ![]() ![]() |
RAID Options | No RAID |
Max HDD Bay | 3 x SATA HDD |
Maximum Storage | 16TB (DW-BJAiMT16T), 24TB (DW-BJAiMT24T), 36TB (DW-BJAiMT36T), 48TB (DW-BJAiMT48T) |
PERFORMANCE | |
Max # of analytic streams (secondary) | Up to 64 |
Performance features | A single device for NVR and Analytics server for lower deployment cost, Deep learning classifiers and logical rules engine, Server-side analytics for non-analytic cameras |
Playback Functions | Calendar, Event search, Smart motion search, Thumbnail search, Timeline |
PTZ control | ONVIF |
Recording Modes | Continuous, Motion + low res always, Motion + Object, Motion + Object + Low res, Motion detection, Object + Low res, Object only |
System Operation | Graphical user interface (GUI), Remote via DW Spectrum IPVMS, USB mouse (included) |
NETWORK | |
Backup | Network backup via DW Spectrum IPVMS |
Ethernet Ports | 2x 1G Ethernet (RJ45) |
Pre-loaded VMS software | DW Spectrum IPVMS |
Network Remote Software | Cross-platform - Windows, Linux Ubuntu and Mac, DW Mobile Plus, DW Spectrum Mobile App |
ELECTRICAL | |
Power Consumption | 500W, A UPS is recommended |
GENERAL | |
Accessories | Keyboard, Mouse |
Ai Configuration Tool supported OS | Cross-platform - Windows and Linux Ubuntu |
Included DW Ai Server Licenses | 4 channel (DW-DWAiSLSC004) |
Included IP licenses | 4 |
Operating Temperature and Humidity | 20 ~ 90% RH, 41 ~ 104 °F (5~40 °C) |
Preloaded Analytic software | DW Ai Server |
Recorder Dimensions (H X W X D) | 7.46” x 15.7” x 14.21” (189.52 x 398.8 x 631.02 mm) |
Recording Licenses (Optional. Sold Separately) | Custom-ordered licenses are available by request. DW-SPCP04LSC004 - Four (4) DW Spectrum Analog Encoder IPVMS Licenses DW-SPCP16LSC016 - Sixteen (16) DW Spectrum Analog Encoder IPVMS Licenses DW-SPECTRUMLSC001 - Single DW Spectrum IPVMS Recording License DW-SPECTRUMLSC004 - Four (4) DW Spectrum IPVMS Recording Licenses DW-SPECTRUMLSC010 - Ten (10) DW Spectrum IPVMS Recording Licenses DW-SPECTRUMLSC020 - Twenty (20) DW Spectrum IPVMS Recording Licenses DW-SPECTRUMLSC050 - Fifty (50) DW Spectrum IPVMS Recording Licenses DW-SPECTRUMLSC100 - One hundred (100) DW Spectrum IPVMS Recording Licenses DW-SPIOLSC001 - Single DW Spectrum I/O Module IPVMS License DW-SPVWALL1X2 - Single DW Spectrum Video Wall IPVMS License Lifetime upgrades are included with no annual renewal fees. |
USB interface | Yes |
Warranty | 5 Year Limited Warranty |
Weight (barebone, HDD not included) | 11.8 lbs (5.35 kg) |
Certification | ![]() ![]() ![]() ![]() ![]() |
Form Factor | Mid-size Tower |
