Blackjack Rack NVR Server (Powered by DW Spectrum IPVMS), 8 DW Spectrum recording licenses and 8 IVA Ai Server licenses pre-installed, 128 cameras @ 2.1MP, 64 analytic streams, Hosting Intelligent Video Analytics Ai software deep learning and color filter, Server-side analytics for non-analytic cameras, Deep learning classifiers, 600 Mbps of recording throughput, Windows 10 Pro on mirrored SSD's, 2000W Dual Power Supply, 2U rack-mount, 80TB usable Raid storage Raid 5, Intel Xeon Gold Processor, 32GB of memory, 2x 10GB SFP+Fiber, 2x 1G Ethernet, Graphic System Health Monitor, True Enterprise Scalability, Automatic Camera Detection, Local Client Display, Fully, Customizable Layouts, Easy Drag and Drop Camera Management and Recording, E-Mapping, Advanced Motion Masking and Sensitivity Settings, Keyboard, Mouse and Rail kit are included, NDAA, TAA, 5 Year Onsite Next Business Day Keep Your Hard Drive Warranty.
Blackjack Ai Rack Artificial Intelligence Network Video Recorders (AI NVR) are purpose-built servers, with built-in server-side analytics that unlock advanced AI capabilities on any connected video stream. These costeffective, plug-and-play appliances combine high-performance recording with video analytics in an easy-to-deploy turnkey solution. The NDAA/TAA compliant, UL listed servers feature up to 320Mbps throughput, an Intel Xeon processor and come preloaded with DW Spectrum IPVMS and eight complimentary recording licenses. Add the power of advanced neuralnetwork-based analytics to your video streams with a Blackjack Ai NVR. The servers come complete with a 5 year, on-site, Next Business Day*, Keep Your Hard Drive warranty to ensure peace of mind.
Features:
Specifications | |
VIDEO | |
CPU | XEON Gold 6248R |
Display Modes | Unlimited, Customizable, Sequence |
Local Video Outputs | For initial system configuration, 1 DisplayPort, 1 display output at a time |
Memory | 32GB |
Video Card | NVIDIA RTX A4000 16GB |
Video Compression | H.264, H.265 |
Video Operating System | Windows® 10 IoT Enterprise LTSC |
OS on SSD | 2 x 240GB NVMe SSD (RAID1) |
Max throughput (Mbps) | 320Mbps |
STORAGE | |
Raw internal storage options | 64TB, 96TB, 128TB, 160TB |
RAID Options | OS RAID1, RAID5 |
Max HDD Bay | 8 x SATA HDD |
Maximum Storage | 160TB RAID 5 (140TB usable storge) (DW-BJAIR160T), 64TB (48TB usable storage) (DW-BJAIR64T), 96TB (80TB usable storage) (DW-BJAIR96T), 160TB |
PERFORMANCE | |
Max # of analytic streams (secondary) | Up to 64 |
Performance features | A single device for NVR and Analytics server for lower deployment cost, AVI file backup, Camera Color Control, Deep learning classifiers and logical rules engine, Import and export settings, Server-side analytics for non-analytic cameras, Watermak exported video |
Playback Functions | Calendar, Event search, Smart motion search, Thumbnail search, Timeline |
PTZ control | ONVIF |
Recording Modes | Continuous, Motion + low res always, Motion + Object, Motion + Object + Low res, Motion detection, Object + Low res, Object only |
System Operation | Graphical user interface (GUI), Remote via DW Spectrum IPVMS, USB mouse (included) |
NETWORK | |
Backup | Network backup via DW Spectrum IPVMS |
Ethernet Ports | 2x 10GB SFP+ Fiber, 2x 1G Ethernet (RJ45), iDRAC9 Enterprise |
Pre-loaded VMS software | DW Spectrum® IPVMS |
Network Remote Software | Cross-platform - Windows®, Linux Ubuntu® and Mac®, DW Mobile Plus, DW Spectrum Mobile App |
ELECTRICAL | |
Power Consumption | 2000W dual power, A UPS is recommended, Redundant power supply |
GENERAL | |
Accessories | Keyboard, Mouse |
Ai Configuration Tool supported OS | Cross-platform - Windows® and Linux Ubuntu® |
General Dimensions | 17.08" x 29.03" x 3.4" (434 x 737.5 x 86.8mm) |
Included DW Ai Server Licenses | 8 (2x DW-DWAiSLSC004) |
Operating Temperature and Humidity | 41 ~ 104 °F (5~40 °C), 5~85% RH |
Preloaded Analytic software | DW Ai Server |
Rail kit | Included |
Recording Licenses (Optional. Sold Separately) | Custom-ordered licenses are available by request. DW-SPCP04LSC004 - Four (4) DW Spectrum® Analog Encoder IPVMS Licenses DW-SPCP16LSC016 - Sixteen (16) DW Spectrum® Analog Encoder IPVMS Licenses DW-SPECTRUMLSC001 - Single DW Spectrum® IPVMS Recording License DW-SPECTRUMLSC004 - Four (4) DW Spectrum® IPVMS Recording Licenses DW-SPECTRUMLSC010 - Ten (10) DW Spectrum® IPVMS Recording Licenses DW-SPECTRUMLSC020 - Twenty (20) DW Spectrum® IPVMS Recording Licenses DW-SPECTRUMLSC050 - Fifty (50) DW Spectrum® IPVMS Recording Licenses DW-SPECTRUMLSC100 - One hundred (100) DW Spectrum® IPVMS Recording Licenses DW-SPIOLSC001 - Single DW Spectrum® I/O Module IPVMS License DW-SPVWALL1X2 - Single DW Spectrum® Video Wall IPVMS License Lifetime upgrades are included with no annual renewal fees. |
USB interface | Yes |
Warranty | keep your hard drive, Next business day on-site hardware service (after remote diagnosis) |
Weight (barebone, HDD not included) | 88.2 lbs (40 kg) |
Form Factor | Rack mount |
