The Blackjack® BOLT™ can record and manage single-sensor IP cameras of any resolution, with an equivalent capacity of up to 16 2.1MP cameras at 30fps and a maximum of 80Mbps throughput. The hardware includes true HD, DVI or Display Port Outputs, Ubuntu® Linux OS, and Dual Ethernet Ports, all packaged in a slim, attractive and compact desktop. The NVR is ONVIF conformant and is available with 2-16TB HDD and 5 Year Limited Warranty.
Maximum IP cameras | 16 (2.1MP/1080p @30fps, with medium recording quality) | |
Included IP licenses | 4 | |
Form factor | Desktop / Cube | |
Operating system | Linux Ubuntu® 64 bit | DW-BJCUBExT-LX |
CPU | Intel® i3® processor | |
Memory | 4GB | |
Option: DW-RME8 - upgrade memory to 8GB* | ||
Ethernet port | 2x gigabit ethernet ports (RJ45) | |
System | Max video storage rate (Mbps) | 80 Mbps |
Storage | Maximum hard drives | 3 x HDD |
Maximum storage | 18TB | |
Video-out | Outputs | DVI-D or True HD output |
Video card | Onboard Intel HD Graphics | |
Resolution | HD 1080p | |
Pre-loaded VMS software | DW Spectrum® IPVMS | |
Remote clients | Cross platform - Windows®, Linux Ubuntu® and Mac® | |
Mobile apps | iOS® and Andriod® | |
Keyboard & mouse | Included | |
Power supply | 300W** | |
Operating temperature and humidity | 41°F~104°F (5°C~40°C) | |
Operating humidity | 20~90% RH | |
Dimension (WxDxH) | 8.5" x 12.8” x 7.5” (215.9 x 325.1 x 190.5 mm) | |
Warranty | 5 year limited |
