Digital Watchdog - DW-BJBOLT8T-LX - Blackjack BOLT-8TB
Part number:
DW-BJBOLT8T-LX
Price:
The Blackjack® BOLT™ can record and manage single-sensor IP cameras of any resolution, with an equivalent capacity of up to 16 2.1MP cameras at 30fps and a maximum of 80Mbps throughput. The hardware includes true HD, DVI or Display Port Outputs, Ubuntu® Linux OS, and Dual Ethernet Ports, all packaged in a slim, attractive and compact desktop. The NVR is ONVIF conformant and is available with 2-16TB HDD and 5 Year Limited Warranty.
- Supports All ONVIF Conformant IP Cameras
- Record up to 16 2.1mp IP cameras with total maximum throughput
- 2TB, 4TB, 8TB,12TB, 16TB internal storage options
- True HD Output, DVI or D-Sub Port
- Dual Network Ports
- Ubuntu® 64Bit Linux® OS
- Hosting DW Spectrum for Setup, Configuration, Monitoring and Recording
- One-time Recording License Charge, Fully Transferable Between Cameras and Encoders
- No Annual Maintenance Fees
- Simple Enterprise Scalability
- Auto Device Discovery
- Dual Stream Recording
- NDAA/TAA compliant
- 5 Year Limited Warranty
|
Maximum IP cameras
|
16 (2.1MP/1080p @30fps, with medium recording quality)
|
|
|
Included IP licenses
|
4
|
|
|
Form factor
|
Desktop / Cube
|
|
|
Operating system
|
Linux Ubuntu® 64 bit
|
DW-BJCUBExT-LX
|
|
CPU
|
Intel® i3® processor
|
|
|
Memory
|
4GB
|
|
|
Option: DW-RME8 - upgrade memory to 8GB*
|
||
|
Ethernet port
|
2x gigabit ethernet ports (RJ45)
|
|
|
System
|
Max video storage rate (Mbps)
|
80 Mbps
|
|
Storage
|
Maximum hard drives
|
3 x HDD
|
|
Maximum storage
|
18TB
|
|
|
Video-out
|
Outputs
|
DVI-D or True HD output
|
|
Video card
|
Onboard Intel HD Graphics
|
|
|
Resolution
|
HD 1080p
|
|
|
Pre-loaded VMS software
|
DW Spectrum® IPVMS
|
|
|
Remote clients
|
Cross platform - Windows®, Linux Ubuntu® and Mac®
|
|
|
Mobile apps
|
iOS® and Andriod®
|
|
|
Keyboard & mouse
|
Included
|
|
|
Power supply
|
300W**
|
|
|
Operating temperature and humidity
|
41°F~104°F (5°C~40°C)
|
|
|
Operating humidity
|
20~90% RH
|
|
|
Dimension (WxDxH)
|
8.5" x 12.8” x 7.5” (215.9 x 325.1 x 190.5 mm)
|
|
|
Warranty
|
5 year limited
|
|
Name
Description
Size
Downloads
File
Data Sheet
0.5mb
File
DW Spectrum IPVMS Ubuntu Installation Guide
1.2mb
File
DW Spectrum IPVMS 2.6 to 3.0 Linux Update Guide
1.9mb
File
AE Spec
0.1mb
