Max throughput and IP camera support

This Blackjack server can record and manage single-sensor and multi-sensor IP cameras of any resolution up to of 80Mbps throughput.

High power output per port

The Blackjack CX PoE NVR delivers local power up to 15W simultaneous on all ports, giving customers significant versatility on camera choices and a simple plug-and-play setup.

Powered by DW Spectrum IPVMS

Blackjack CX recorders offer the full capabilities of DW Spectrum IPVMS without the hassle of wiring cameras to a power supply on an affordable stand-alone NVR.

Dual network cards

Optimize network bandwidth by utilizing dual network ports, to build a separate network for the surveillance system and keep that traffic off the main network, reserved for the NVR’s communication.

Designed and commissioned in the U.S.A

All DW recorders, workstations and NAS devices are designed, assembled and inspected in our California facility. Each product undergoes multiple levels of quality control to guarantee the highest quality and performance.

Features

• Supports all ONVIF conformant IP cameras
• Storage options 4-40TB internal storage
• Record and manage up to 24 IP cameras with local PoE support for 16 channels
• Record and manage single- and multi-sensor IP cameras of any resolution up to 80Mbps throughput
• Intel processor
• 1xTrue HD, 1x DVI, 1 display output at a time
• Dual network ports
• 4 alarm inputs, 2 alarm outputs (Under development)
• 1 audio input, 1 audio output, 1 microphone input
• One-time recording license charge, fully transferable between cameras and encoders
• One (1) 4-channel licenses included (DW-SPECTRUMLSC004)
• No annual maintenance fees
• Simple enterprise scalability and auto device discovery
• Dual stream recording
• USB mouse and keyboard included
• DW-BJCXRM rack mount ears included with the recorder
• Wall mount available. Sold separately
• Designed, assembled and tested in the U.S.A.
• NDAA/TAA compliant
• 5 Years limited warranty
