Digital Watchdog - DW-BJDX7124T - Blackjack DX7 NVR Powered by DW Spectrum IPVMS. 4 camera licenses pre-installed, 24TB, 480 Mbps of recording throughput, 1x True HD, 1x DP, Windows 10 OS, i7 Processor, Dual Network Card, OnVIF compliant, Graphic Sys
Part number:
DW-BJDX7124T
Price:

Blackjack DX7 NVR Powered by DW Spectrum IPVMS.  4 camera licenses pre-installed, 24TB, 480 Mbps of recording throughput,  1x True HD, 1x DP, Windows 10 OS,  i7 Processor, Dual Network Card, OnVIF  compliant,  Graphic System Health Monitor for hardware performance, True Enterprise Scalability, Automatic Camera Detection, Local Client Display, Fully Customizable Layouts, Easy Drag and Drop Camera Management and Recording, E-Mapping, Advanced Motion Masking and Sensitivity Settings, NDAA, TAA. Keyboard and Mouse Included. 5 Year Limited Warranty



Blackjack DX slim desktop servers are reliable and highperformance solutions for viewing, monitoring and recording multiple IP cameras of any resolution at up to 480Mbps throughput. The servers are NDAA and TAA compliant and include Windows 10 OS on a separate SSD. Hardware features include an Intel 12th generation processor, dual network cards and local video output for system configuration. The servers come pre-loaded with DW Spectrum IPVMS and four complimentary recording licenses, provide up to 40TB internal storage, are ONVIF conformant and come with a 5-year limited warranty.



Features:

  • Supports all ONVIF conformant IP cameras
  • Storage options 4-40TB internal storage
  • Record and manage single- and multi-sensor IP cameras of any resolution up to 480Mbps throughput
  • Intel i7 processor
  • True HD, DP, 1 display output at a time
  • 1x 1G Ethernet, 1x 2.5G Ethernet
  • Windows 10 on separate SSD
  • Hosting DW Spectrum for setup, configuration, monitoring and recording
  • One-time recording license charge, fully transferable between cameras and encoders
  • One (1) 4-channel license included (DW-SPECTRUMLSC004)
  • No annual maintenance fees
  • Simple enterprise scalability and auto device discovery
  • Dual stream recording
  • USB mouse and keyboard included
  • Designed, assembled and tested in the U.S.A.
  • NDAA/TAA compliant
  • 5 Years limited warranty
VIDEO
CPUIntel i7 processor
Display ModesUnlimited, Customizable, Sequence
Local Video Output Resolution5120x3200 (DP, 120Hz), 7680x4320 (DP, 60Hz), 4096x2160 (True HD)
Local Video OutputsFor initial configuration and server management, 1 DisplayPort, True HD, 1 display output at a time
Memory16GB
Video CardOn-board Intel Graphics
Video CompressionH.264, H.265
Video Operating SystemWindows 10 IoT Enterprise LTSC
OS on SSDm.2 SSD
Max throughput (Mbps)480Mbps
STORAGE
Raw internal storage options004TB008TB012TB016TB020TB024TB032TB040TB
RAID OptionsNo RAID
Max HDD Bay2 x SATA HDD
Maximum Storage12TB (DW-BJDX7112T), 16TB (DW-BJDX7116T), 24TB (DW-BJDX7124T), 4TB (DW-BJDX7104T), 8TB (DW-BJDX7108T), 20TB (DW-BJDX7120T), 32TB (DW-BJDX7132T), 40TB (DW-BJDX7140T)
PERFORMANCE
Playback FunctionsCalendar, Event search, Smart motion search, Thumbnail search, Timeline
PTZ controlONVIF
Recording ModesContinuous, Motion + low res always, Motion + Object, Motion + Object + Low res, Motion detection, Object + Low res, Object only
System OperationGraphical user interface (GUI), Remote via DW Spectrum IPVMS, USB mouse (included)
NETWORK
BackupNetwork backup via DW Spectrum IPVMS
Ethernet Ports1x 1G Ethernet (RJ45), 1x 2.5G Ethernet (RJ45)
Pre-loaded VMS softwareDW Spectrum IPVMS
Network Remote SoftwareCross-platform - Windows, Linux Ubuntu and Mac, DW Spectrum Mobile App
ELECTRICAL
Power Consumption300W, A UPS is recommended
GENERAL
AccessoriesKeyboard, Mouse
Included IP licenses4
Operating Temperature and Humidity20 ~ 90% RH, 41 ~ 104 °F (5~40 °C)
Recorder Dimensions (H X W X D)Desktop: 3.88” x 13.1” x 15.8” (98.5 x 334 x 402 mm)
Recording Licenses (Optional. Sold Separately)Custom-ordered licenses are available by request.
DW-SPCP04LSC004 - Four (4) DW Spectrum Analog Encoder IPVMS Licenses
DW-SPCP16LSC016 - Sixteen (16) DW Spectrum Analog Encoder IPVMS Licenses
DW-SPECTRUMLSC001 - Single DW Spectrum IPVMS Recording License
DW-SPECTRUMLSC004 - Four (4) DW Spectrum IPVMS Recording Licenses
DW-SPECTRUMLSC010 - Ten (10) DW Spectrum IPVMS Recording Licenses
DW-SPECTRUMLSC020 - Twenty (20) DW Spectrum IPVMS Recording Licenses
DW-SPECTRUMLSC050 - Fifty (50) DW Spectrum IPVMS Recording Licenses
DW-SPECTRUMLSC100 - One hundred (100) DW Spectrum IPVMS Recording Licenses
DW-SPIOLSC001 - Single DW Spectrum I/O Module IPVMS License
DW-SPVWALL1X2 - Single DW Spectrum Video Wall IPVMS License
Lifetime upgrades are included with no annual renewal fees.
USB interfaceYes
Warranty5 Year Limited Warranty
Weight (barebone, HDD not included)15.65 lbs (7.09 kg)
CertificationCEFCCNDAA ComplianceONVIF ConformantTAA Compliance
Form FactorSlim Desktop
