Digital Watchdog - DW-BJDXCLIENT4 - Blackjack DX Workstation, Windows 11 OS, 32GB RAM
• Supports all ONVIF conformant IP cameras
• Connect up to two (2) monitors simultaneously (DW-BJDXCLIENT2)
• Connect up to four (4) monitors simultaneously (DW-BJDXCLIENT4)
• Local monitoring ports for DW Spectrum servers monitoring
• Windows 11 IoT Enterprise LTSC
• OS on separate SSD reduces the risk of data corruption
• Hosting DW Spectrum client for monitoring
• USB mouse and keyboard included for local setup and control
• Designed, assembled and tested in the U.S.A.
• NDAA/TAA compliant for federal and government projects
• 5 Years limited warranty
| Hardware | |
| CPU | Intel i7® processor (DW-BJDXCLIENT2) Intel i9 processor (DW-BJDXCLIENT4) |
| Display Speed | Up to 30fps per channel |
| Local Video Output Resolution | 7680x4320 (8K) per port |
| Local Video Outputs | 1x True HD output, 1x DisplayPort output (DW-BJDXCLIENT2) 1x True HD output, 3x DisplayPort outputs (DW-BJDXCLIENT4) Up to 2 ports simultaneously (DW-BJDXCLIENT2) Up to 4 displays simultaneously (DW-BJDXCLIENT4) |
| Maximum number of cameras per layout | Up to 8 cameras per layout |
| Memory | 16GB (DW-BJDXCLIENT2) 32GB (DW-BJDXCLIENT4) |
| Video Card | nVidia® RTX 5060 8GB (DW-BJDXCLIENT4) nVidia® RTX 3050 6GB (DW-BJDXCLIENT2) |
| OS on SSD | 256GB M.2 SSD |
| Storage | |
| Raw internal storage options | 004TB |
| Max HDD Bay | 1 x SATA HDD |
| Maximum Storage | For local video export |
| VMS features | |
| Playback Functions | Calendar Event search Smart motion search Thumbnail search Timeline |
| PTZ control | ONVIF |
| System Operation | Graphical user interface (GUI) Remote via DW Spectrum USB mouse (included) |
| Network | |
| Ethernet Ports | 1x 1G Ethernet (RJ45) 1x 2.5Gb Ethernet (RJ45) |
| Pre-loaded VMS software | DW Spectrum® Client |
| General | |
| Accessories | Keyboard Mouse |
| Operating Temperature and Humidity | 20 ~ 90% RH 41 ~ 104 °F (5~40 °C) |
| Recorder Dimensions (H X W X D) | Standing: 13.1" x 3.88" x 15.8" (334 x 98.5 x 402 mm) Desktop: 3.88" x 13.1" x 15.8" (98.5 x 334 x 402 mm) |
| USB interface | Yes |
| Warranty | 5 Year Limited Warranty |
| Weight (barebone, HDD not included) | 15.65 lbs (7.09 kg) |
| Certification | NDAA ONVIF Conformant TAA Compliance |
| Form Factor | Slim Desktop |
The Blackjack DX clients are dynamic workstations powered by DW Spectrum. They enable users to view and monitor multiple DW Spectrum servers on up to four monitors from a single location. Offloading monitoring to a dedicated workstation means that Blackjack servers can operate at optimal performance, while the workstations deliver high-quality video monitoring capabilities without impacting server performance.
