20TB HDD
Make big things happen — record locally, monitor centrally and manage remotely.™ The Blackjack® MINI™ makes big things happen! The server allows you to record locally, combine into a centralized monitoring system via DW Spectrum® IPVMS and managed remotely, from anywhere, any time. The server can record and manage single-sensor IP cameras of any resolution, with maximum of 60 Mbps throughput (equivalent to 12 2.1MP/1080p cameras at 30fps). Manage remotely with DW Spectrum® Client or the DW Spectrum Mobile® app. The Blackjack® MINI™ is an ideal solution for any small scale application or for remote locations with a small number of cameras but no need for local monitoring. The server has 5 years limited warranty, is ONVIF conformant and is available with 2-20TB HDD.
Maximum IP cameras
|
12 (2.1MP/1080p @30fps, with medium recording quality), or 60Mbps total throughput.
|
|
Form factor
|
Slim desktop
|
|
Operating system
|
Embedded Linux®
|
DW-BJMINIxT, DW-BJMINIRxT
|
Ethernet port
|
1x gigabit ethernet port (RJ45), can configure up to 2 IP subnets
|
|
System
|
Max video storage rate (Mbps)
|
60 Mbps
|
Storage
|
Maximum hard drives
|
2 x SATA HDD
|
Maximum storage
|
DW-BJMINIxT: 20TB DW-BJMINIxTR: 10TB, RAID 1 |
|
Local video output | NA | |
Pre-loaded VMS software
|
DW Spectrum® IPVMS server
|
|
Remote clients
|
Cross-platform - Windows®, Linux Ubuntu® and Mac®
|
|
Mobile apps
|
iOS® and Andriod®
|
|
Power supply
|
36W
|
|
Operating temperature and humidity
|
41°F~104°F (5°C~40°C)
|
|
Operating humidity
|
20~90% RH
|
|
Dimension (WxDxH)
|
9.84" x 10.74" x 1.96" (250 x 273 x 50mm)
|
|
Warranty
|
5 year limited
|
