Digital Watchdog - DW-BJMT7132TS - Blackjack Tower Mid-Size Servers with Intel Core i7 Processor, Windows Server OS, 32TB
Part number:
DW-BJMT7132TS
Price:

Blackjack® Tower™ mid-size servers are reliable and high-performance solutions for recording multiple IP cameras of any resolution at up to 480Mbps throughput. The servers are UL-listed and NDAA/TAA compliant and include Windows 10® or Windows Server® OS on a separate SSD. Hardware features include a 9th generation Intel® Core™ i7 processor, 16GB RAM, dual network cards and local output up to 4K resolution for system configuration. The servers come preloaded with DW Spectrum® IPVMS and four recording licenses, provide up to 48TB internal storage, are ONVIF conformant and come with a 5 year limited warranty.


All Blackjack® Tower servers come with one (1) DW-SPECTRUMLS004 4-channel license included.



Features:

  • Supports all ONVIF conformant IP cameras
  • Up to 48TB internal storage
  • OS on SSD
  • Record and manage single- and multi-sensor IP cameras of any resolution up to 480Mbps throughput
  • 1 x True HD, 1 x DVI, 1 x VGA, 1 display output at a time
  • Dual network ports
  • Windows 10® and Windows® Server® OS options
  • Hosting DW Spectrum® for setup, configuration and recording
  • One-time recording license charge, fully transferable between cameras and encoders
  • One (1) 4-channel license included (DW-SPECTRUMLSC004)
  • No annual maintenance fees
  • Simple enterprise scalability
  • Auto device discovery
  • Dual-stream recording
  • USB mouse and keyboard included
  • Designed, assembled and tested in the U.S.A.
  • UL Listed
  • NDAA/TAA compliant
  • 5 year limited warranty
MODELSDW-BJMT31xxT/LXDW-BJMT51xxT/LXDW-BJMT71xxT/LX
Included IP licenses444
Form factorMid-size towerMid-size towerMid-size tower
Operating systemWindows®10DW-BJMT31xxTDW-BJMT51xxTDW-BJMT71xxT
Linux® Ubuntu®DW-BJMT31xxTLXDW-BJMT51xxTLX---
Windows® Server®------DW-BJMT71xxTS
OS on SSD240GB SSD240GB SSD240GB SSD
CPU9th generation Intel® i3® processor9th generation Intel® i5® processor9th generation Intel® i7® processor
Memory8GB16GB16GB
Ethernet port2 x 1Gigabit Ethernet (RJ45)2 x 1Gigabit Ethernet (RJ45)2 x 1Gigabit Ethernet (RJ45)
SystemMax video storage rate (Mbps)180Mbps360Mbps480 Mbps
StorageMaximum storage drives3 x 3.5 SATA HDD3 x 3.5 SATA HDD3 x 3.5 SATA HDD
Maximum storage20TB48TB48TB
Video-outOutputs1 x true HD, 1 x DVI, 1 x VGA. Maximum 1 display output at a time
Video cardOnboard Intel graphics
Preloaded VMS softwareDW Spectrum® IPVMS
Remote clientsCross-platform - Windows®, Linux® Ubuntu® and Mac®
Mobile appsiOS® and Andriod®
DW Site Viewer
DW Spectrum App
Keyboard and mouseIncluded
Power supply400W**400W**400W**
Operating temperature (ambient room temperature)41°F~104°F (5°C~40°C)
Operating humidity20~90% RH
Dimension (WxDxH)7.46” x 15.7” x 14.21” (189.52 x 398.8 x 631.02 mm)
Other certificationsUL listed, ONVIF, NDAA/TAA, CE, FCC
Warranty5 year limited
