Digital Watchdog - DW-BJNAS4T - Blackjack NAS Desktop Storage, ARM Cortex-A9 Dual-core-1.0ghz, 512MB RAM, Linux embedded, 4TB
Part number:
DW-BJNAS4T
Price:

DW Blackjack Network Attached Storage, Linux Embedded OS, 4 terabyte, 160Mbps, 1Gigabit Ethernet, Web Viewer 12vdc. 5 Year Limited Warranty.



Centralize your file storage, sharing and backup with excellent performance

The Blackjack NAS products offer the ideal supplement for existing systems with optimized network load and continuous archiving. Critical video and audio can be stored for a longer time.



Add and manage recording from the DW Spectrum IPVMS client software

The Blackjack NAS units are integrated into the DW Spectrum IPVMS software, allowing for simple addition, removal and recording setup all done from the same user-friendly UX of the DW Spectrum IPVMS client.



Blackjack NAS storage for MEGApix CaaS systems

Blackjack NAS devices can be implemented into a MEGApix CaaS network, offering lower costs and greater flexibility than adding new servers to an existing system.



Designed and commissioned in the U.S.A

All DW recorders, workstations and NAS devices are designed, assembled and inspected in our California facility. Each product undergoes multiple levels of quality control to guarantee the highest quality and performance.




Features :

  • Centralize your file storage and backup with excellent performance
  • Expands recording capacity of any MEGApix CaaS camera solution OR Blackjack NVR system
  • Add and DW Spectrum IPVMS client software
  • Seamless search via the DW Spectrum IPVMS client, including smart motion search, spyglass and calendar search options.
  • Add a NAS station to a MEGApix CaaS network with up to 24 cameras
  • Add a NAS station to a Blackjack server to quickly expand local storage and backup up to 120Mbps throughput.
  • Storage options 4-12TB internal storage
  • RAID1 option (DW-BJNASxTR models)
  • Linux embedded OS
  • Attractive and slim desktop design to compliment any application
  • NDAA/TAA compliant
  • 5 year warranty
Specification:
Part NumberDW-BJNASxT
Operating systemLinux® embedded
Form factorDesktop
CPUARM Cortex-A9 dual-core@1.0ghz
RAM512MB
Flash memory128MB
Maximum hard drives2 x SATA HDD
Maximum storage capacity20TB (2 x 10TB)
RAIDN/A
File systemEXT4
Max. recording channel

24 with MEGApix® CaaS™

Max 24 2.1MP cameras with Blackjack® Bolt™ and Blackjack® Cube™

Max. recording bandwidthMax. 120Mbps throughput
LAN1 x gigabit ethernet (RJ45 connector)
ProtocolSMB, HTTP, SMTP, NTP
Remote configurationDW Spectrum® IPVMS Client, Blackjack® NAS web viewer
Supported browsersMicrosoft® IE® 10 or higher, Google® Chrome® 57 or higher, Mac® Safari® 9 or higher (required), Firefox® 43 or higher
LED indicatorsHDD status, power
Operating temperature41°F~104°F (5°C~40°C)
Operating humidity20~90% (RH) non-condensing
Power supplyDC 12V
Power consumption36W, 3A
Dimensions (WxDxH)10.2” x 11.02” x 2.1” (258 x 280 x 53mm)
WeightGross: 4.73lbs (2.1Kg), Net: 3.3lbs (1.5Kg), Gross: 6.16lbs (2.8Kg), Net: 3.3lbs (1.5Kg)
Warranty5 year limited
