Blackjack P-RACK™ NVRs powered by DW Spectrum™ IPVMS, 30TB usable RAID storage, 4 camera licenses pre-installed, Manage up to 128 2.1MP 1080p IP cameras at up to 30fps, 600 Mbps throughput. RAID 5 hard drive configuration, Intel® i7® Processor and 16GB Memory. Standard features include Windows® 10 OS on an SSD HDD, scheduled auto reboot for hardware performance, cross platform connectivity for Windows® and Mac® client software, 2x NIC cards, DVI and true HD output, Automatic Camera Detection, Fully Customizable Layouts, Easy Drag and Drop Camera Management and Recording, E-Mapping, Advanced Motion Masking and Sensitivity Settings. OnVIF conformant, Keyboard and mouse included. 5 Year Limited Warranty.
Blackjack® P-Rack™ servers can record and manage single- and multi-sensor IP cameras of any resolution, with an equivalent capacity of up to 128 2.1MP cameras at 30fps and a maximum of 600Mbps throughput. Standard features include Intel® i7®, Windows® 10 Pro or Linux® Ubuntu® OS and 2x NIC cards. Blackjack® P-Rack™ servers can be configured with 30-50TB recording storage and come with our 5 year limited warranty.
All Blackjack® P-RACK NVR models come with a DW-SPECTRUMLS004 4-channel license included.
For additional license part numbers click here
- Supports All ONVIF conformantIP cameras
- Storage options 40-60TBinternal storage
- Data redundancy
- Record and manage single- andmulti-sensor IP cameras of any resolution up to 128 2.1MP cameras at 30fps anda maximum of 600Mbps throughput
- True HD and DVI localmonitoring outputs ports
- Dual network ports
- Windows® 10 Pro or Linux®Ubuntu® 16.04 OS on separate SSD
- USB interface
- Hosting DW Spectrum® IPVMSfor setup, configuration, monitoring and recording
- One-time recording licensecharge, fully transferable between cameras and encoders
- One (1) DW Spectrum® IPVMS4-channel licenses included (DW-SPECTRUMLSC004)
- No annual maintenance fees
- Simple enterprise scalability
- Auto device discovery
- Dual stream recording
- Rail kit included
- USB mouse and keyboardincluded
- Designed, assembled andtested in the U.S.A.
- NDAA/TAA compliant
- 5 years limited warranty
|
Maximum IP cameras
|
128 (2.1MP/1080p @30fps, with medium recording quality)
|
|
|
Included IP licenses
|
4
|
|
|
Form factor
|
Rack mount
|
|
|
Operating system
|
Windows® 10 Pro
|
DW-BJPR2UXXT
|
|
Linux Ubuntu® 16.04
|
DW-BJPR2UXXT-LX
|
|
|
OS on SSD
|
150GB SSD
|
|
|
|
||
|
CPU
|
Intel®i7® processor
|
|
|
Memory
|
16GB
|
|
|
Ethernet port
|
2x gigabit ethernet ports (RJ45)
|
|
|
Option: DW-R4NIC - upgrade quad 1GB NIC card *
|
||
|
System
|
Max video storage rate (Mbps)
|
600 Mbps
|
|
Storage
|
Maximum hard drives
|
6 x SATA HDD
|
|
Maximum storage
|
50TB RAID 5
|
|
|
Video-out
|
Outputs
|
True HD output or VGA or DVI
|
|
Video card
|
GeForce 210 512MB
|
|
|
Option: DW-RV4H - 4 head HD video card*
|
||
|
Resolution
|
HD 1080p
|
|
|
Pre-loaded VMS software
|
DW Spectrum® IPVMS
|
|
|
Remote clients
|
Cross platform - Windows®, Linux Ubuntu® and Mac®
|
|
|
Mobile apps
|
iOS® and Andriod®
|
|
|
Keyboard & mouse
|
Included
|
|
|
Rail kit
|
Included
|
|
|
Power supply
|
400W**
|
|
|
Operating temperature and humidity
|
41°F~104°F (5°C~40°C)
|
|
|
Operating humidity
|
20~90% RH
|
|
|
Dimension (WxDxH)
|
17.32" x 26" x 19" (439.9 x 660.4 x 482.6 mm)
|
|
|
Warranty
|
5 year limited
|
|
